MR-HIGH VOLTAGE RECTIFIER
.25 (TYP)
.12 R
Please Note:
Different Circuit Arrangements are identified
by using a Circuit Code Letter.
P=Positive Center Tap
N=Negative Center Cap
D=Doubler
1.38 MAX .17
L
.37 (TYP)
.63
Positive Center Tap (P)
Positive Center Tap 1.2A, 5000V/
LEG
MRP5000
Negative Center Tap (N)
FIGURE
9
Negative Center Tap 2.5A, 1500V/
LEG
MRSN15000
Doubler (D)
(I
FAVM
of Doubler is I
FAVM
x 0.5)
Fast Recovery Doubler 1.0A, 7500V/
LEG
MRFSD7500
Max. Surge
Current
I
FSM
(8.3ms)
A(Amps)
50
50
50
50
50
50
50
50
50
150
150
150
150
150
150
150
150
150
50
50
50
50
50
50
50
50
50
100
100
100
100
100
100
100
100
50
50
50
50
50
50
150
150
150
150
150
150
50
50
50
50
50
50
100
100
100
100
100
Max.
Reverse
Recovery Time
T
rr
(nsec)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
150
150
150
150
150
150
150
150
150
250
250
250
250
250
250
250
250
-
-
-
-
-
-
-
-
-
-
-
-
150
150
150
150
150
150
250
250
250
250
250
.20 (TYP)
Repetitive Peak
Avg. Forward
Max. Forward
Max. Reverse
Reverse Voltage
Current Max.
Voltage Drop
Current I
R
@
HVCA
V
RRM
Per Leg
I
FAVM
@55°C
V
F
@I
F
Per Leg
I
F
@V
RRM
@25°C
Number
V(Volts)
A (Amps)
V(Volts)
µ
A(microAmps)
MR–Standard Recovery 1.0 Amp Glass Passivated Rectifier Assembly
MR2500
2500
0.6
2.4
0.5
MR5000
5000
0.6
4.5
0.5
MR7500
7500
0.6
7.2
0.5
MR10000
10000
0.6
9.0
0.5
MR12500
12500
0.6
11.0
0.5
MR15000
15000
0.6
14.0
0.5
MR20000
20000
0.6
18.0
0.5
MR25000
25000
0.8
22.0
0.5
MR30000
30000
0.8
28.0
0.5
MRS–Standard Recovery 3.0 Amp Glass Passivated Rectifier Assembly
MRS2500
2500
1.25
2.4
0.5
MRS5000
5000
1.25
4.5
0.5
MRS7500
7500
1.25
7.2
0.5
MRS10000
10000
1.25
9.0
0.5
MRS12500
12500
1.25
11.0
0.5
MRS15000
15000
1.25
14.0
0.5
MRS20000
20000
1.25
18.0
0.5
MRS25000
25000
1.25
22.0
0.5
MRS30000
30000
1.25
28.0
0.5
MRF–Fast Recovery T
rr
150 nsec 1.0 Amp Glass Passivated Rectifier Assembly
MRF2500
2500
0.5
6.0
0.5
MRF5000
5000
0.5
9.0
0.5
MRF7500
7500
0.5
12.0
0.5
MRF10000
10000
0.5
15.0
0.5
MRF12500
12500
0.5
20.0
0.5
MRF15000
15000
0.5
24.0
0.5
MRF20000
20000
0.5
30.0
0.5
MRF25000
25000
0.5
40.0
0.5
MRF30000
30000
0.5
48.0
0.5
MRFS–Fast Recovery T
rr
250 nsec 3.0 Amp Glass Passivated Rectifier Assembly
MRFS2500
2500
1.0
4.0
0.5
MRFS5000
5000
1.0
7.0
0.5
MRFS7500
7500
1.0
11.0
0.5
MRFS10000
10000
1.0
13.0
0.5
MRFS12500
12500
1.0
17.0
0.5
MRFS15000
15000
1.0
22.0
0.5
MRFS20000
20000
1.0
28.0
0.5
MRFS30000
30000
1.0
34.0
0.5
MR•–Standard Recovery 1.0 Amp Glass Passivated Rectifier Center Tap and Doubler Assembly
MR•2500
2500
1.2
2.4
0.5
MR•5000
5000
1.2
4.5
0.5
MR•7500
7500
1.2
7.2
0.5
MR•10000
10000
1.2
9.0
0.5
MR•12500
12500
1.2
11.0
0.5
MR•15000
15000
1.2
14.0
0.5
MRS•–Standard Recovery 3.0 Amp Glass Passivated Rectifier Center Tap and Doubler Assembly
MRS•2500
2500
2.5
2.4
0.5
MRS•5000
5000
2.5
4.5
0.5
MRS•7500
7500
2.5
7.2
0.5
MRS•10000
10000
2.5
9.0
0.5
MRS•12500
12500
2.5
11.0
0.5
MRS•15000
15000
2.5
14.0
0.5
MRF•–Fast Recovery T
rr
150 nsec 1.0 Amp Glass Passivated Rectifier Center Tap and Doubler Assembly
MRF•2500
2500
1.0
6.0
0.5
MRF•5000
5000
1.0
9.0
0.5
MRF•7500
7500
1.0
12.0
0.5
MRF•10000
10000
1.0
16.0
0.5
MRF•12500
12500
1.0
20.0
0.5
MRF•15000
15000
1.0
24.0
0.5
MRFS•–Fast Recovery T
rr
250 nsec 3.0 Amp Glass Passivated Rectifier Center Tap and Doubler Assembly
MRFS•2500
2500
2.0
4.0
0.5
MRFS•5000
5000
2.0
7.0
0.5
MRFS•7500
7500
2.0
11.0
0.5
MRFS•10000
10000
2.0
13.0
0.5
MRFS•12500
12500
2.0
17.0
0.5
Case
Length
L (Inches)
Figure 9
3.36
3.36
3.36
3.36
4.04
4.04
4.72
5.08
6.09
Figure 9
3.36
4.04
4.04
4.04
4.72
6.09
6.09
6.09
6.09
Figure 9
3.36
3.36
4.04
4.04
4.72
6.09
6.09
6.09
6.09
Figure 9
3.36
4.04
4.72
6.09
6.09
6.09
6.09
6.09
Figure 9
3.36
4.04
4.72
4.72
6.09
6.09
Figure 9
3.36
4.72
6.09
6.09
6.09
6.09
Figure 9
3.36
4.72
6.09
6.09
6.09
6.09
Figure 9
4.04
6.09
6.09
6.09
6.09
DIODES
15
