DM74LS151 1-of-8 Line Data Selector/Multiplexer
August 1986
Revised March 2000
DM74LS151
1-of-8 Line Data Selector/Multiplexer
General Description
This data selector/multiplexer contains full on-chip decod-
ing to select the desired data source. The DM74LS151
selects one-of-eight data sources. The DM74LS151 has a
strobe input which must be at a low logic level to enable
these devices. A high level at the strobe forces the W out-
put HIGH, and the Y output LOW.
The DM74LS151 features complementary W and Y out-
puts.
Features
s
Select one-of-eight data lines
s
Performs parallel-to-serial conversion
s
Permits multiplexing from N lines to one line
s
Also for use as Boolean function generator
s
Typical average propagation delay time data input to
W output 12.5 ns
s
Typical power dissipation 30 mW
Ordering Code:
Order Number
DM74LS151M
DM74LS151SJ
DM74LS151N
Package Number
M16A
M16D
N16E
Package Description
16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150 Narrow
16-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
16-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300 Wide
Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.
Connection Diagram
Truth Table
Inputs
Select
C
X
L
L
L
L
H
H
H
H
B
X
L
L
H
H
L
L
H
H
A
X
L
H
L
H
L
H
L
H
Strobe
S
H
L
L
L
L
L
L
L
L
Outputs
Y
L
D0
D1
D2
D3
D4
D5
D6
D7
W
H
D0
D1
D2
D3
D4
D5
D6
D7
H
=
HIGH Level
L
=
LOW Level
X
=
Don't Care
D0, D1...D7
=
the level of the respective D input
© 2000 Fairchild Semiconductor Corporation
DS006392
www.fairchildsemi.com
DM74LS151
Absolute Maximum Ratings
(Note 1)
Supply Voltage
Input Voltage
Operating Free Air Temperature Range
Storage Temperature Range
7V
7V
0°C to
+70°C
−65°C
to
+150°C
Note 1:
The “Absolute Maximum Ratings” are those values beyond which
the safety of the device cannot be guaranteed. The device should not be
operated at these limits. The parametric values defined in the Electrical
Characteristics tables are not guaranteed at the absolute maximum ratings.
The “Recommended Operating Conditions” table will define the conditions
for actual device operation.
Recommended Operating Conditions
Symbol
V
CC
V
IH
V
IL
I
OH
I
OL
T
A
Supply Voltage
HIGH Level Input Voltage
LOW Level Input Voltage
HIGH Level Output Current
LOW Level Output Current
Free Air Operating Temperature
0
Parameter
Min
4.75
2
0.8
−0.4
8
70
Nom
5
Max
5.25
Units
V
V
V
mA
mA
°C
Electrical Characteristics
over recommended operating free air temperature range (unless otherwise noted)
Symbol
V
I
V
OH
V
OL
Parameter
Input Clamp Voltage
HIGH Level
Output Voltage
LOW Level
Output Voltage
I
I
I
IH
I
IL
I
OS
I
CC
Input Current @ Max Input Voltage
HIGH Level Input Current
LOW Level Input Current
Short Circuit Output Current
Supply Current
Conditions
V
CC
=
Min, I
I
= −18
mA
V
CC
=
Min, I
OH
=
Max
V
IL
=
Max, V
IH
=
Min
V
CC
=
Min, I
OL
=
Max
V
IL
=
Max, V
IH
=
Min
I
OL
=
4 mA, V
CC
=
Min
V
CC
=
Max, V
I
=
7V
V
CC
=
Max, V
I
=
2.7V
V
CC
=
Max, V
I
=
0.4V
V
CC
=
Max (Note 3)
V
CC
=
Max (Note 4)
−20
6
2.7
3.4
0.35
0.25
0.5
0.4
0.1
20
−0.4
−100
10
mA
µA
mA
mA
mA
Min
Typ
(Note 2)
Max
−1.5
Units
V
V
V
Note 2:
All typicals are at V
CC
=
5V, T
A
=
25°C.
Note 3:
Not more than one output should be shorted at a time, and the duration should not exceed one second.
Note 4:
I
CC
is measured with all outputs OPEN, strobe and data select inputs at 4.5V, and all other inputs OPEN.
3
www.fairchildsemi.com
