SILICON EPITAXIAL
PNP TRANSISTOR
BCY71DCSM
•
Low Current / Low Voltage Transistor
In A Dual Ceramic Hermetic Package
•
Designed For General Purpose
Industrial Applications
•
Screening Options Available
ABSOLUTE MAXIMUM RATINGS
(TA = 25°C unless otherwise stated)
VCBO
VCEO
VEBO
IC
ICM
PD
TJ
Tstg
Collector - Base Voltage
Collector - Emitter Voltage
Emitter – Base Voltage
Continuous Collector Current
Peak Collector Current
TA = 25°
C
Total Power Dissipation at
Derate Above 25°
C
Junction Temperature Range
Storage Temperature Range
Each Side Total Device
-45V
-45V
-5V
-200mA
-200mA
350mW
500mW
*
2mW/°
C
2.9mW/°
C
-65 to +200°
C
-65 to +200°
C
THERMAL PROPERTIES
(Each Side.)
Symbols Parameters
R
θJA
Thermal Resistance, Junction To Ambient
R
θJC
Thermal Resistance, Junction To Case
* Total device power dissipation limited by package.
Min.
Typ. Max. Units
500 °
C/W
150 °
C/W
Semelab Limited reserves the right to change test conditions, parameter limits and package dimensions without notice.
Information furnished by Semelab is believed to be both accurate and reliable at the time of going to press. However
Semelab assumes no responsibility for any errors or omissions discovered in its use. Semelab encourages customers to
verify that datasheets are current before placing orders.
Semelab Limited
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Telephone +44 (0) 1455 556565
Fax +44 (0) 1455 552612
Email:
sales@semelab.co.uk
Document Number 8108
Issue 1
Website:
http://www.semelab.co.uk
SILICON EPITAXIAL
PNP TRANSISTOR
BCY71DCSM
ELECTRICAL CHARACTERISTICS
(Each Side, TA = 25°C unless otherwise stated)
Symbols
ICES
IEBO
VCE(sat)**
VBE(sat)**
Parameters
Collector-Emitter Cut-Off
Current
Emitter-Base Cut-Off
Current
Collector-Emitter
Saturation Voltage
Base-Emitter
Saturation Voltage
Test Conditions
VCE = -20V
VCE = -45V
VEB = -5V
IC = -10mA
IC = -50mA
IC = -10mA
IC = -50mA
IC = -0.01mA
IC = -0.1mA
VBE = 0
VBE = 0
IC = 0
IB = -1.0mA
IB = -5mA
IB = -1.0mA
IB = -5mA
VCE = -1.0V
VCE = -1.0V
VCE = -1.0V
VCE = -1.0V
VCE = -1.0V
Min. Typ. Max. Units
-0.1
-10
10
-0.25
-0.5
-0.6
-0.9
-1.2
60
80
90
100
15
600
V
µA
hFE**
Forward-current transfer
ratio
IC = -1.0mA
IC = -10mA
IC = -50mA
DYNAMIC CHARACTERISTICS
IC = -0.1mA
fT
Transition Frequency
f = 10.7MHz
IC = -10mA
f = 100MHz
hfe
Cobo
Cibo
Small-Signal Current Gain
IC = -1.0mA
f = 1.0KHz
IE = 0
f = 1.0MHz
IC = 0
f = 1.0MHz
IC = -0.1mA
Rg = 2K
IC = -1.0mA
f = 1.0KHz
IC = -1.0mA
f = 1.0KHz
IC = -1.0mA
f = 1.0KHz
VCE = -10V
10
VCE = -10V
VCE = -5V
2
VCE = -10V
dB
VEB = -1.0V
VCB = -10V
VCE = -10V
VCE = -20V
VCE = -20V
15
MHz
250
100
400
Output Capacitance
Input Capacitance
6
pF
8
NF
Noise Figure
f = 10Hz To 10KHz
hie
hre
hoe
Input Impedance
Reverse Voltage Ratio
2
12
20
-4
x 10
60
µS
K
Output Admittance
** Pulse Test: tp = 300us,
δ ≤
2%
Semelab Limited
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Telephone +44 (0) 1455 556565
Fax +44 (0) 1455 552612
Email:
sales@semelab.co.uk
Document Number 8108
Issue 1
Website:
http://www.semelab.co.uk
SILICON EPITAXIAL
PNP TRANSISTOR
BCY71DCSM
Mechanical Data
Dimensions in mm (inches)
2.29 ± 0.20
(0.09 ± 0.008)
1.65 ± 0.13
(0.065 ± 0.005)
1.40 ± 0.15
(0.055 ± 0.006)
0.64 ± 0.06
(0.025 ± 0.003)
2.54 ± 0.13
(0.10 ± 0.005)
2
1
A
3
4
5
6
0.23 rad.
(0.009)
A = 1.27 ± 0.13
(0.05 ± 0.005)
6.22 ± 0.13
(0.245 ± 0.005)
LCC2 (MO-041BB)
Underside View
Pad 1 – Collector 1
Pad 2 – Base 1
Pad 3 – Base 2
Pad 4 – Collector 2
Pad 5 – Emitter 2
Pad 6 – Emitter 1
Semelab Limited
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Telephone +44 (0) 1455 556565
Fax +44 (0) 1455 552612
Email:
sales@semelab.co.uk
Website:
http://www.semelab.co.uk
Document Number 8108
