RA Series T1 3/4
Right Angle LED Bar*
Special Features
*Patented
• Customized to your specifications without tooling charges
— Variable LED spacing, minimum .280˝ maximum bar length 6˝
— Variable color sequence
• Available with 2 to 22 T1 3/4 LEDs in one convenient assembly
• Bar provides consistent LED alignment for multiple LED mounting
• Available with a variety of LEDs
• Wave solderable and chemically cleanable
• Housing and bar material UL 94V-0 rated
5mm PC Board Mount LEDs
Electrical and Optical Characteristics (TA=25°C)
LED
Part#
Color
Luminous
Intensity (mcd)
Typ.@IF(mA)
VF Typ.@IF (mA)
Viewing
Angle
2Θ
2
Peak
More
Wavelength LED Data
(mm)
Page#
Package Dimensions
6.00 MAX.
(152.4)
.280 MIN.
(7.1)
.200 DIA.
(5.0)
HIGH EFFICIENCY
3008
3019
3020
3022
Red
Green
Yellow
Orange
7.0
14.0
8.0
7.0
10
10
10
10
1.9
2.1
2.0
1.9
10
10
10
10
60°
60°
60°
60°
635
565
583
600
24
24
24
24
.040
(1.0)
LOW CURRENT
3015
3016
3017
Red
Yellow
Green
2.3
2.1
2.3
2
2
2
1.8
1.9
1.8
2
2
2
50°
50°
50°
635
583
565
25
25
25
.122 (3.1)
.263
(6.7)
.280
(7.1)
BEVELED CORNER
FOR CATHODE LEAD
(Red/Yellow Cathode for Bicolor)
.410
(10.4)
.300 (7.6)
.260 (6.6)
.135
(3.4)
5V INTERNAL RESISTOR
3040
3042
3043
Red
Yellow
Green
40.0
16.0
16.0
12
12
12
5.0
5.0
5.0
12
12
12
60°
60°
60°
625
590
565
26
26
26
.180
(4.6)
.020 SQ.
(0.5)
.100
(2.5)
.202
(5.1)
All Dimensions are in inches (mm)
BLUE
3044
3045
Blue
Blue
40.0
90.0
20
20
4.5
4.5
20
20
60°
16°
430
430
30
30
How To Order
INDIVIDUAL RA LEDs
BICOLOR
9001
9002
Red
Green
Yellow
Green
30.0
25.0
15.0
25.0
20
20
20
20
2.0
2.2
2.1
2.2
20
20
20
20
60°
60°
625
565
590
565
27
27
R A x — x x x x
LED Color
Red = R
Yellow = Y
Green = G
Orange = O
Bicolor = B
Blue = L
White = W
ULTRA BRIGHT - DAYLIGHT READABLE
3056
3055
3054
Red
Yellow
Green
500.0
500.0
300.0
20
20
20
1.9
2.1
3.5
20
20
20
60°
60°
60°
660
595
525
24
24
24
See LED Chart
for Part #
SUPER ULTRA BRIGHT
3036
3046
3047
3048
Red
Red
Green
Amber
2500.0
900.0
1750.0
1300.00
20
20
20
20
1.85
1.9
3.5
2.02
20
20
20
20
30°
30°
30°
30°
660
635
524
592
29
29
29
29
MULTIPLE RA LEDs ON A BAR
x R A x — x x x x — x x x
# of LEDs
Per Bar
LED Color
Red = R
Yellow = Y
Green = G
Orange = O
Bicolor = B
Blue = L
White = W
Multiple = M
Center to Center
Spacing of LEDs
in inches
See LED Chart
(If spacing varies,
for Part #
use SPL)
(Use MCOO
for multiple
colors)
WHITE
3058
White
1198.0
20
3.65
20
20°
N/A
30
®
WILBRECHT
ELECTRONICS, INC.
LEDCO
DIVISION
6
