7314A-FREQ-NSA3289H datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> 7314A-FREQ-NSA3289H

7314A-FREQ-NSA3289H: DescriptionCMOS Output Clock Oscillator, 25MHz Min, 52MHz Max, ROHS COMPLIANT PACKAGE-6; CategoryPassive components oscillator; File Size79KB，1 Pages; ManufacturerNDK; Websitehttp://www.ndk.com/en/; Environmental Compliance

Download Datasheet Parametric View All

7314A-FREQ-NSA3289H Overview

CMOS Output Clock Oscillator, 25MHz Min, 52MHz Max, ROHS COMPLIANT PACKAGE-6

7314A-FREQ-NSA3289H Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	unknown
Other features	STANDBY FUNCTION
Maximum control voltage	4.5 V
Minimum control voltage	0.5 V
Frequency Adjustment - Mechanical	NO
Frequency offset/pull rate	100 ppm
frequency stability	40%
Manufacturer's serial number	7314A
Installation features	SURFACE MOUNT
Maximum operating frequency	52 MHz
Minimum operating frequency	25 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
Oscillator type	CMOS
Output load	15 pF
physical size	14.0mm x 9.6mm x 6.4mm
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
maximum symmetry	60/40 %
Base Number Matches	1

Preview

Download Datasheet

View All

Crystal Oscillator

Model Name 7314A

Main Application

ISDN- and SDH-related equipment

Voltage-Controlled Crystal Oscillator (VCXO) 7300 Series

Features

Both TTL and C-MOS IC are directly driven.

A surface-mount crystal oscillator.

Complies with the RoHS Directive.

Specifications

Model

Classification

Item

Nominal frequency range [f] (MHz)

Power supply voltage [VCC] (V)

Current consumption (mA)

Output level

Duty cycle (%)

Load

Operating temperature range (℃)

Frequency stability

Frequency control characteristic

Control polarity

Standby function

None

Available

None

Min. ±100 × 10

−6

/ +2.5 ± 2.0 V

Positive

Available

None

Available

TTL level

45 to 55 (< 25 MHz),

40 to 60 (≥ 25 MHz)

(+1.4 V)

N-TTL2

−10 to +70

Max. ±40 × 10

−6

Min. ±70 × 10

−6

/ +1.65 ± 1.5 V

+5 ± 5 %

Max. 30

C-MOS level

45 to 55 (< 25 MHz),

40 to 60 (≥ 25 MHz)

(1/2 VCC)

15 pF

SV71-A

SV71-E

7314A

See *1 shown below.

SV81-A

2 to 52

+3.3 ± 5 %

Max. 20

SV81-E

SV81-D

SV81-F

Dimensions

14A

PAD No.

9.6 ± 0.2

Connection

VCONT

NC or STAND-BY

GND

OUTPUT

VCC

Nominal frequency (MHz)

2 ≤ f < 25

25 ≤ f ≤ 52

Classification

6.4 ± 0.3

List of Ordering Codes

Model Name and Frequency

Classification

(MHz)

7314A-GSV71-A

7314A-GSV71-E

Ordering Code

]M-NSA3289A

]M-NSA3289B

]M-NSA3289E

]M-NSA3289F

]M-NSA3289C

]M-NSA3289D

]M-NSA3289G

]M-NSA3289H

]M-NSA3289J

]M-NSA3289K

]M-NSA3289L

]M-NSA3289M

14.0 ± 0.4

1.0 ± 0.2

1.3

#2 #3

Reference land pattern

#6 #5

2-2.54 ± 0.2

2.54

2 ≤ f < 25 7314A-[

7314A-ASV71-A 25 ≤ f ≤ 52 7314A-[

7314A-ASV71-E 25 ≤ f ≤ 52 7314A-[

7314A-GSV81-A 2 ≤ f < 25 7314A-[

7314A-GSV81-E 2 ≤ f < 25 7314A-[

7314A-ASV81-A 25 ≤ f ≤ 52 7314A-[

7314A-ASV81-E 25 ≤ f ≤ 52 7314A-[

7314A-GSV81-D 2 ≤ f < 25 7314A-[

7314A-GSV81-F 2 ≤ f < 25 7314A-[

7314A-ASV81-D 25 ≤ f ≤ 52 7314A-[

7314A-ASV81-F 25 ≤ f ≤ 52 7314A-[

2.6 2.9 2.9 2.6

6.0 ± 0.2

GND THROUGH HOLE

Specify a frequency in the square brackets.

Specify the frequency in seven digits (the decimal point is not included).

Omit zeros after the decimal point.

co32_090417_7314A_e
