U1ZB18 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> U1ZB18

U1ZB18: DescriptionZener Diode; Configuration: Single; Tolerance: 0.1; VZ Typ (V): 18; P Max (mW): 1000; Package: SMA; Pin: Z1; CategoryDiscrete semiconductor diode; File Size600KB，5 Pages; ManufacturerGalaxy Microelectronics

Download Datasheet Parametric View All

U1ZB18 Overview

Zener Diode; Configuration: Single; Tolerance: 0.1; VZ Typ (V): 18; P Max (mW): 1000; Package: SMA; Pin: Z1

U1ZB18 Parametric

Parameter Name	Attribute value
Parts packaging code	SMA
Reach Compliance Code	unknown
Configuration	SINGLE
Diode type	ZENER DIODE
Maximum dynamic impedance	30 Ω
Number of components	1
Maximum operating temperature	150 °C
Maximum power dissipation	1 W
Nominal reference voltage	18 V
surface mount	YES
Maximum voltage tolerance	10%
Working test current	10 mA
Base Number Matches	1

Preview

Download Datasheet

View All

Production specification

Zener Diodes

Features



Silicon planar power ,zener diodes

For use in stabilizing and clipping circuits with high

power rating.

Standard zener voltage tolerance is ±10%. Add

suffix "A" for ±5% tolerance. Other zener voltage

and tolerances are available upon request.

Case: SMA molded plastic

Molding compound, UL flammability classification rating 94V-0

Terminals: Solder plated, solderable per MIL- STD-202,Method 208

Polarity: Color band denotes cathode end

U1ZB3.3--U1ZB390

Mechanical Data

Maximum Ratings

(@T

= 25°C unless otherwise specified)

Parameter

Power dissipation at Tamb=25°C

Junction temperature

Storage temperature range

Symbol

Ptot

Value

1.01)

-40---+150

Units

°C

Notes:

1.Valid provided that leads at a distance of 10 mm from case are kept at ambient temperature.

SMA001AA

Rev.B

www.gmesemi.com
