RoHS Compliant
22.8 x 15.3 x 25.8 mm
A1
Features
•
•
•
•
•
Switching capacity up to 25A
Small size and light weight
PCB pin and quick connect mounting available
Suitable for automobile and lamp accessories
QS-9000, ISO-9002 Certified Manufacturing
Contact Data
Contact Arrangement
Contact Rating
1A = SPST N.O.
1C = SPDT
Specifications and availability subject to change without notice.
Contact Resistance
Contact Material
Maximum Switching Power
Maximum Switching Voltage
Maximum Switching Current
< 50 milliohms initial
AgSnO
2
350W
75VDC
25A
1A : 25A @ 14VDC
1C : 20A @ 14VDC
Coil Data
Coil Voltage
VDC
Rated
6
12
24
48
Max
7.8
15.6
31.2
62.4
Coil Resistance
Ω
+/- 10%
1.2W
30
120
480
1920
1.5W
24
96
384
1536
Pick Up Voltage Release Voltage
VDC (max)
VDC (min)
70% of rated
voltage
4.20
8.40
18.00
33.60
10% of rated
voltage
.6
1.2
2.4
4.8
1.20 or 1.50
10
7
Coil Power
W
Operate Time
ms
Release Time
ms
General Data
Dimensions shown in mm. Dimensions are shown for reference purposes only.
Electrical Life @ rated load
Mechanical Life
Insulation Resistance
Dielectric Strength, Coil to Contact
Contact to Contact
Shock Resistance
Vibration Resistance
Terminal (Copper Alloy) Strength
Operating Temperature
Storage Temperature
Solderability
Weight
100K cycles, typical
10M cycles, typical
100M
Ω
min. @ 500VDC
2500V rms min. @ sea level
1500V rms min. @ sea level
100m/s
2
for 11 ms
1.27mm double amplitude 10~40Hz
8N (Quick Connect), 4N (PCB pins)
-40
o
C to +85
o
C
-40
o
C to +155
o
C
260
o
C for 5 s
18.5g
Caution
1. The use of any coil voltage less than the
rated coil voltage may compromise the
operation of the relay.
www.citrelay.com
phone - 763.535.2339
fax - 763.535.2194
A1
Ordering Information
1. Series
A1
2. Contact Arrangement
1A = SPST N.O.
1C = SPDT
3. Sealing Option
S = Sealed
4. Termination
P = PCB Pins
Q = Quick Connect
5. Coil Voltage
6VDC
12VDC
24VDC
48VDC
6. Coil Power
1.2 = 1.2W
1.5 = 1.5W
7. Coil Suppression
Blank = Standard
D = Diode (1N4005)
R = Resistor (680 ohms)
** Consult factory if other values are needed
A1
1A
S
Q
12VDC
1.2
Dimensions shown in mm. Dimensions are shown for reference purposes only.
Dimensions
Units = mm
PC Pin Dimensions
Units = mm
Specifications and availability subject to change without notice.
Schematics & PC Layouts
Bottom Views
1A
www.citrelay.com
phone - 763.535.2339
fax - 763.535.2194
1C
