Type 936C
Axial Leaded Metallized Polypropylene Capacitor
High Current Flat Axial Leaded Capacitors
Type 936C flat axial leaded meltallized polypropylene capaci-
tors are designed for 20 to 100 kHz switching power supply
input filtering, DC blocking and output filter applications
where high current, high capacitance and low ESR values
are important. Dry sections are sealed with flame retandant
outer wrap and epoxy end seals for moisture resistance.
Highlights
•
Low ESR
•
High current
•
Flame retardant outer wrap and end seals
Specifications
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Operating
Temperature Range:
Dielectric Strength:
Dissipation Factor:
Insulation Resistance:
Life Test:
0.47 to
10.0
µF
400 to 600 Vdc (250 to 330 Vac)
±10% Standard, ±5% Optional
–55 ºC to 105 ºC with full rated voltage at 85 ºC,
derate lineraly to 50% of rated voltage at 105 ºC
200% of rated voltage for 1 minute
0.10% Max (25 ºC, 1 kHz)
200,000 MΩ x µF
1,000 hours at 85 ºC at 125% rated voltage
Outline Drawing
Complies with the EU Directive 2002/95/EC
requirement restricting the use of Lead (Pb), Mercury
(Hg), Cadmium (Cd), Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB) and PolyBrominated
Diphenyl Ethers (PBDE).
W ±.06"
(1.5mm)
Ratings
Cap.
(µF)
.47
.68
1.0
1.5
2.0
2.2
3.3
4.7
6.8
10.0
0.47
0.68
1.0
1.5
2.2
Catalog
Part Number
936C4P47K-F
936C4P68K-F
936C4W1K-F
936C4W1P5K-F
936C4W2K-F
936C4W2P2K-F
936C4W3P3K-F
936C4W4P7K-F
936C4W6P8K-F
936C4W10K-F
936C6P47K-F
936C6P68K-F
936C6W1K-F
936C6W1P5K-F
936C6W2P2K-F
T
Maximum
Inches (mm)
0.280
0.300
0.390
0.480
0.480
0.560
0.690
0.640
0.670
0.700
0.460
0.550
0.670
0.730
0.640
(7.1)
(7.6)
(9.9)
(12.2)
(12.2)
(14.2)
(17.5)
(16.3)
(17.0)
(17.8)
(11.7)
(14.0)
(17.0)
(18.5)
(16.3)
1.625"
(41mm)
MIN.
L ±.05"
(1.2mm)
1.625"
(41mm)
MIN.
T MAX.
W
L
±.06" (1.5)
±.05" (1.2)
Inches (mm)
Inches (mm)
400 Vdc (250 Vac)
0.470 (11.9)
1.250 (31.75)
0.530 (13.5)
1.250 (31.75)
0.590 (15.0)
1.250 (31.75)
0.690 (17.5)
1.250 (31.75)
0.690 (17.5)
1.250 (31.75)
0.830 (21.1)
1.250 (31.75)
0.930 (23.6)
1.250 (31.75)
0.880 (22.4)
1.750 (44.45)
0.900 (22.9)
2.250 (57.15)
1.050 (26.7)
2.250 (57.15)
600 Vdc (330 Vac)
0.690 (17.5)
1.250 (31.75)
0.790 (20.1)
1.250 (31.75)
0.910 (23.1)
1.250 (31.75)
0.970 (24.6)
1.500 (38.10)
0.880 (22.4)
2.250 (57.15)
d
Inches (mm)
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.040
0.040
0.040
0.032
0.032
0.032
0.032
0.040
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(1.0)
(1.0)
(1.0)
(0.8)
(0.8)
(0.8)
(0.8)
(1.0)
ESR
IRMS
(milliohms) A
@
70ºC
100 KHz
100 KHz
21
13
11
9
9
8
7
7
7
7
13
10
8
7
10
4
6
9
10
10
11
15
17
17
17
4
6
9
11
13
CDE
Cornell
Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8561
•
Fax: (508)996-3830
•
www.cde.com
