97 series crimp type
plugs with solid shells
97-4106A
Connector
Size
L Max.
Inch
mm
Inch
N Ref.
mm
Inch
Q Max.
mm
V
Fitting Threads
97-4106A straight plug
Sturdy, simple to assemble. Coupling ring
machined from solid aluminum bar stock for
high tensile strength. Mates with all types of
MS receptacles. Front shell includes polariz-
ing keyway. Back shell is threaded for stan-
dard MS/AN fittings.
10SL
12S
14S
16S
18
20
22
24
28
32*
36*
1-3/8
1-7/16
1-15/32
1-15/32
1-31/32
1-7/8
1-31/32
2-1/4
2-1/4
2-3/8
2-3/8
34.93
36.50
37.13
37.13
49.88
47.50
49.88
57.15
57.15
60.33
60.33
3/4
25/32
7/8
1
1-1/8
1-1/4
1-3/8
1-1/2
1-3/4
2-1/32
2-1/4
19.05
19.84
22.23
25.40
28.57
31.75
34.93
38.10
44.45
51.59
57.15
7/8
1
1-1/8
1-1/4
1-11/32
1-15/32
1-19/32
1-23/32
1-31/32
2-7/32
2-15/32
22.23
25.40
28.58
31.75
34.11
37.29
40.46
43.64
49.99
56.34
62.69
5/8-24
5/8-24
3/4-20
7/8-20
1
-20
1-3/16-18
1-3/16-18
1-7/16-18
1-7/16-18
1-3/4-18
2
-18
97-4107A
Connector
Size
L Max.
Inch
mm
Inch
N Ref.
mm
Inch
Q Max.
mm
V
Fitting Threads
10SL
12S
14S
16S
16
18
20
22
24
28
32*
36*
1-3/8
1-7/16
1-15/32
1-15/32
1-7/8
1-31/32
1-7/8
1-31/32
2-1/4
2-1/4
2-3/8
2-3/8
34.92
36.50
37.13
37.13
47.47
49.88
47.50
49.88
57.15
57.15
60.33
60.33
3/4
25/32
7/8
1
1
1-1/8
1-1/4
1-3/8
1-1/2
1-3/4
2-1/32
2-1/4
19.05
19.84
22.23
25.40
25.40
28.58
31.75
34.93
38.10
44.45
51.59
57.15
7/8
1
1-1/8
1-1/4
1-1/4
1-11/32
1-15/32
1-19/32
1-23/32
1-31/32
2-7/32
2-15/32
22.23
25.40
38.58
31.75
31.75
34.11
37.29
40.46
43.64
49.99
56.34
62.69
1
5/8-24
5/8-24
3/4-20
7/8-20
7/8-20
-20
1-3/16-18
1-3/16-18
1-7/16-18
1-7/16-18
1-3/4-18
2
-18
97-4107A quick-disconnect plug
For fast connect/disconnect applications.
Front shell has polarizing keyway. Mates
with all types of MS receptacles. Back shell
is threaded for standard MS/AN fittings
97-4108A
Connector
Size
L Ref.
Inch
mm
Q Max.
Inch
mm
U Ref.
Inch
mm
V
Fitting Threads
Y Ref.
Inch
mm
10SL
12S
14S
16S
18
20
22
24
28
1-5/16
1-3/8
1-3/8
1-1/2
1-15/16
2-1/16
2-1/16
2-15/32
2-15/32
33.32
34.93
34.93
38.10
49.20
52.37
52.37
62.69
62.69
7/8
1
1-1/8
1-1/4
1-11/32
1-15/32
1-19/32
1-23/32
1-31/32
22.23
25.40
28.58
31.75
34.11
37.29
40.46
43.64
49.99
1
1
1
1-1/8
1-1/8
1-5/16
1-5/16
1-1/2
1-1/2
25.40
25.40
25.40
28.58
28.58
33.32
33.32
38.10
38.10
5/8-24
5/8-24
3/4-20
7/8-20
1 -20
1-3/16-18
1-3/16-18
1-7/16-18
1-7/16-18
1-1/16
1-1/16
1-1/16
1-5/16
1-5/16
1-5/8
1-5/8
2
2
26.97
26.97
26.97
33.32
33.32
42.28
42.28
50.80
50.80
97-4108A angle plug
For use where space in front of panel or wall
is at a premium. Swivel ring and plate com-
bination allow cable take off at any angle rel-
ative to front shell polarizing key. Back shell
is threaded for standard MS/AN fittings.
* Available for 97-4106A only.
25
