IF SAW Filter
Part Number
Package
Application
Last Modified
835-IF75.0M-F
.
TYPE :
35.0 x 12.8 Thru Hole
Base Station & Repeater
May 24 2003
75.0 MHz Bandpass Filter
19.0 MHz Bandwidth
PART NUMBER :
835-IF75.0M-F
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
18dB Bandwidth
33dB Bandwidth
50dB Bandwidth
Passband Ripple
Group Delay Variation
Ultimate Rejection
Absolute Delay
Ambient Temperature
Minimum
-
-
18.70
19.00
-
-
-
-
-
50
-
-
Typical
75.00
24.50
18.85
19.17
19.95
20.28
20.48
0.65
50
55
2.87
25
Maximum
-
26.0
-
-
20.10
20.40
20.70
1.0
100
-
-
-
Units
MHz
dB
MHz
MHz
MHz
MHz
MHz
dB
nsec
dB
µsec
°C
* Custom SAW IF Filters available. Contact Oscilent for assistance.
.
PACKAGE OUTLINE
(mm)
TEST FIXTURE
L1 = 120nH
L2 = 180nH
C1 = 56pF
C2 = 39pF
Source/Load Impedance = 50 ohms
Part No.:
835-IF75.0M-F
http://www.oscilent.com/spec_pages/if_sawfilter/if_835_if75_0f.htm
12/28/2005
