Broadband Standard Product
PA020180-3025-SS-H High Power Amplifier Module
Broadband Power 2GHz to 18GHz
June 13, 2007
www.aeroflex.com/bband
DESCRIPTION
Our new innovative broadband power amplifier designs provide
performance without sacrificing output power. The ultra wideband
performance of the PA020180-3025-SS can replace multiple narrowband
power amplifiers, there by reducing cost and complexity in microwave
systems.
Our team of engineers can custom design power amplifiers using the latest
simulation software and proprietary technology to meet even the most
demanding specifications.
FEATURES
❑
❑
❑
❑
❑
❑
❑
❑
>30dBm P1dB up to 18GHz
30dB Typical Gain
7dB NF @ 16GHz (Typical)
IP3 > 40dBm @ 8GHz
Single Power Supply
High Efficiency
Compact Size
Hermetic Package
SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
1
PARAMETER
Operating Temperature – Case
Storage Temperature – Case
Positive Supply Voltage
SYMBOL
T
MO
T
MS
V
PS
MIN
-40
-40
+12
MAX
+65
+125
+15
UNITS
°C
°C
V
1. Stresses above those listed under "Absolute Maximums Rating" may cause permanent damage to the device. This is a stress rating only and functional
operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
NOMINAL OPERATING CONDITIONS
PARAMETER
Temperature, T
C
– Case
Positive Supply Voltage, V
PS
Aeroflex Plainview
SCD10029 Rev B
CONDITIONS
Full Range
MIN
-40
+12
MAX
+55
+15
UNITS
°C
V
SPECIFICATIONS
ELECTRICAL CHARACTERISTICS @ +25°C
PARAMETER
Frequency Range
Power Output
Power Output Saturated
Gain
Gain Flatness
Noise Figure
RF Input Return Loss
RF Output Return Loss
Positive Supply Voltage
Positive Supply Current +12V, +15V
@ 8GHz
2 - 18GHz, Reference to 50 ohms
4 - 18GHz, Reference to 50 ohms
1dB Compression Point
Saturated Power
CONDITIONS
MIN
2.0
+29
+30
25
-1.5
-
-
-
+12
-
TYP
-
+32
+33
-
-
6.5
10
10
-
-
MAX
18
+33
+35
-
+1.5
-
-
-
+15
2.4
UNIT
GHz
dBm
dBm
dB
dB
dB
dB
dB
V
Amps
TYPICAL S-PARAMETERS
SCD10029 Rev B 6/13/07
Aeroflex Plainview
2
OUTLINE DRAWING
.420 MAX
.235
.170
2X .180
.400
.200
6X
R.054
1.615 MAX
.095
6X
PA020180-3025-SS-H
+12V
GND
2.705 MAX
2.510
2.340
ESD
RF IN
.305 2X
RF OUT
.175
2X
.050
2X
.250
2X
.800
2X
1.350
2X
2.132
ORDERING INFORMATION
MODEL NUMBER
PA020180-3025-SS-H
HERMETICITY
Hermetic
PACKAGE
2.70L x 1.615W x .39Ht
PLAINVIEW, NEW YORK
Toll Free: 800-THE-1553
Fax: 516-694-6715
SE AND MID-ATLANTIC
Tel: 321-951-4164
Fax: 321-951-4254
INTERNATIONAL
Tel: 805-778-9229
Fax: 805-778-1980
WEST COAST
Tel: 949-362-2260
Fax: 949-362-2266
NORTHEAST
Tel: 603-888-3975
Fax: 603-888-4585
CENTRAL
Tel: 719-594-8017
Fax: 719-594-8468
www.aeroflex.com
info-ams@aeroflex.com
Aeroflex Microelectronic Solutions reserves the right to
change at any time without notice the specifications, design,
function, or form of its products described herein. All
parameters must be validated for each customer's application
by engineering. No liability is assumed as a result of use of
this product. No patent licenses are implied.
SCD10029 Rev B 6/13/07
