AFCL060115NJW2G

Description
Feed Through Capacitor, 1 Function(s), 630V, 10A
CategoryAnalog mixed-signal IC    filter
File Size205KB,1 Pages
ManufacturerNissei Electric Co.,Ltd.
Download Datasheet Parametric View All

AFCL060115NJW2G Overview

Feed Through Capacitor, 1 Function(s), 630V, 10A

AFCL060115NJW2G Parametric

Parameter NameAttribute value
Reach Compliance Codeunknown
ECCN codeEAR99
capacitance1500 µF
Maximum DC resistance0.006 Ω
filter typeFEED THROUGH CAPACITOR
Maximum insertion loss43 dB
Manufacturer's serial numberAFCL060
Installation typePANEL MOUNT
Number of functions1
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Rated current10 A
Rated voltage630 V
Base Number Matches1
Small Signal Feed Through Filters
CL configuration, film dielectric
Feed through filter range using film capacitor technology to achieve
good temperature stability. The units are housed in robust, sealed
metal containers of threaded construction, and offer a range of
terminal finishes. Specifically designed for military, industrial,
telecoms and medical applications, but especially suitable for use
where fast rising transients are liable to be encountered.
AFCL
060 series
Capacitive values from 1500pF - 47nF
Self healing capacitors
Wide choice of performance options
Superior pulse current capability
Excellent temperature stability
Wire or tag termination options
Mechanical Specifications
Manufacture:
resin sealed metal containers.
Connections:
wire or tag terminations.
Electrical Specifications
Rated voltage (V
R
):
Rated current (I
R
):
see table
referred to room temperature = 40°C
1.6 V
R
dc
(55/125/56;)
Temperature range: -55°C to +125°C
5/16-24 UNF
5/16-24 UNF
Category voltage (V
C
):
see table
Voltage test (2
S
.):
Case Variants
Style
1
2
Length (mm)
L1 max
6.1
6.1
L2 max
8
12
Wire dia.
± 0.2mm
1
1
Thread
Climatic category:
Filter Range - AFCL060
(example pt no. - AFCL060115NJW1T)
Code
Max values C
IR(A) Rdc (pF)
dc or
Dimensions (mm) and connections
V
C
V
R
Typical Insertion
loss (dB)
Pulse
capability
V/us
± 20% dc ac
6
6
6
6
6
6
6
6
6
1500
5000
dc ac
(MHz)
10
8
16
20
30
8
13
20
28
37
30 100 400
18 27
28 38
30 40
40 47
18 27
25 35
30 40
36 45
47
51
43
53
58
63
43
53
58
63
68
rms (mΩ) at 1kHz
115NJ-1- 10
150LJ-1- 10
210JJ-1- 10
227DJ-1- 10
115NJ-2- 10
130NJ-2- 10
210LJ-2- 10
227JJ-2- 10
247DJ-2- 10
rms
rms 1
630 125 300 125 -
350 125 200 115 -
100 -
50 -
-
10
2000
1200
1200
1200
2000
2000
720
720
720
10000 250 -
27000 100 -
1500
3000
630 150 400 125 -
630 150 300 125 -
100 -
50 -
10
16
10000 350 125 200 115 -
27000 250 -
47000 100 -
Case finish: T = Tin plated
S = Silver plated
G = Gold plated
Case style
Termination: W = Wire
T = Tag
at 400Hz
Circuit diagram (CL configuration)
ac voltage ratings below 115V have
not been specified.
Approvals
58
00
BS 9121
F0021
Meet MIL-F-15733 requirements
