Oscilent Corporation IF SAW Filter | 820-IF70.0M-Y
Page 1 of 2
IF SAW Filter
Part Number
Package
Application
Last Modified
820-IF70.0M-Y
.
TYPE :
20.2 x 12.6 Thru Hole
Base Station & Repeater
May 02 2003
70.0 MHz Bandpass Filter
12.1 MHz Bandwidth
PART NUMBER :
820-IF70.0M-Y
.
Horizontal : 3.0 MHz/Div
Veritical : 10 dB/Div
Horizontal : 1.6 MHz/Div
Veritical : 1 dB/Div
Veritical : 100 ns/Div
.
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
40dB Bandwidth
Passband Ripple
Group Delay Variation
Absolute Delay
Ultimate Rejection
Substrate Material
Ambient Temperature
Phase Linearity
Minimum
69.90
-
11.6
12.1
-
-
-
-
50
-
-
-
Typical
70.00
23.0
11.9
12.4
14.0
0.8
40
2.28
55
YZ-LN
25
4.5
Maximum
70.10
26.0
-
-
14.5
1.0
70
-
-
-
-
7.0
Units
MHz
dB
MHz
MHz
MHz
dB
nsec
µsec
dB
-
°C
degc
* Custom SAW IF Filters available. Contact Oscilent for assistance.
.
PACKAGE OUTLINE
(mm)
TEST FIXTURE
http://www.oscilent.com/spec_pages/if_sawfilter/if_820_if70_0y.htm
12/28/2005
Oscilent Corporation IF SAW Filter | 820-IF70.0M-Y
Page 2 of 2
L1 =
L2 =
150nH
3.3nH
Source/Load Impedance = 50 ohms
Part No.:
820-IF70.0M-Y
