C
ONNECTORIZED
A
TTENUATORS
WITH
D
IGITAL
C
ONNECTORS
D
ESCRIPTION
Designed for high
speed/medium power applica-
tions, these digital attenua-
tors feature nine-pin micro-D
connectors that easily inte-
grate to control logic with-
out the need for soldered con-
nections. Both the digital
and the RF connectors are on
one side for easy cable con-
nection. Hermetic,
military/industrial design.
A
DDITIONAL
F
EATURES
(#8166)
E
LECTRICAL
C
HARACTERISTICS
PART #
TYPE
FREQ
RANGE
GH
Z
LOSS
dB
ATTEN
RANGE
dB
VSWR
SWITCH
SPEED
ns
RF
POWER
dBm
DC
SUPPLY
Volts
s
Power:
2 Watts
C
ONNECTORS
8165
8166
8167
8168
6 Bit
4 Bit
4 Bit
6 Bit
2-8
.8-1.2
.8-1.2
.5-4
3.8
2.5
2.5
4.0
31.5
67.5
60
63
1.8:1
1.8:1
1.8:1
1.8:1
150
50
50
200
27
33
33
20
+5,-15
+5,-15
+5,-15
+5,-5
s
SMA
O
PERATING
E
NVIRONMENT
P
ACKAGE
O
UTLINE
s
Operating Temperature:
-55 to +125°C
s
Storage Temperature:
-65 to +150°C
s
Impedance:
50 ohm
s
Control:
Transistor-Transistor Logic
(TTL)
A
PPLICATIONS
s
Radar simulation
s
Electronic Warfare (EW)
s
Radar stimulator
MICRONETICS / 26 HAMPSHIRE DRIVE / HUDSON, NH 03051 / TEL: 603-883-2900 / FAX: 603-882-8987 / CUSTOMER HOTLINE: 1-800-963-3382 / WEB: WWW.MICRONETICS.COM
