Oscilent Corporation IF SAW Filter | 815-IF43.75M-B
Page 1 of 2
IF SAW Filter
Part Number
Package
Application
Last Modified
815-IF43.75M-B
.
TYPE :
15.9 x 5.9 Thru Hole
Digital A/V & Broadcasting
May 22 2003
43.75 MHz Bandpass Filter
6.2 MHz Bandwidth
PART NUMBER :
815-IF43.75M-B
.
Horizontal : 1.5 MHz/Div
Veritical : 10 dB/Div
Horizontal : 0.8 MHz/Div
Veritical : 1 dB/Div
Veritical : 100 ns/Div
.
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency
Insertion Loss
3 dB Bandwidth
30 dB Bandwidth
Lower Sidelobe (35.0 ~ 39.7 MHz)
Upper Sidelobe (47.8 ~ 55.0 MHz)
Passband Ripple
Group Delay Variation
Absolute Delay (at Fo)
Temperature Coefficient
Minimum
43.68
-
6.2
-
35
34
-
-
-
-
Typical
43.75
13.0
6.24
7.63
35.7
35.6
0.6
60
1.38
-72
Maximum
43.82
15.0
-
7.68
-
-
1.0
100
-
-
Units
MHz
dB
MHz
MHz
dB
dB
dB
nsec
µsec
ppm/K
* Custom SAW IF Filters available. Contact Oscilent for assistance.
.
PACKAGE OUTLINE
(mm)
TEST FIXTURE
http://www.oscilent.com/spec_pages/if_sawfilter/if_815_if43_75b.htm
12/28/2005
Oscilent Corporation IF SAW Filter | 815-IF43.75M-B
Page 2 of 2
Source Impedance = 50 ohms
Load Impedance = 2 Kohms / 3pF
Part No.:
815-IF43.75M-B
