802-RF902.5M-C Overview

Wireless, RF SAW Filter

802-RF902.5M-C Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerOscilent
Reach Compliance Codecompli
Center frequency or cutoff frequency (fo/fc)902.5 MHz
filter typeSAW FILTER
high1.3 mm
input resistance50 OHM
Maximum insertion loss3.5 dB
length3 mm
Manufacturer's serial number802-RF902.5M-C
Installation typeSURFACE MOUNT
Number of functions1
Maximum operating temperature65 °C
Minimum operating temperature-30 °C
Output impedance50 OHM Ω
physical sizeL3.0XB3.0XH1.3 (mm)/L0.118XB0.118XH0.051 (inch)
RF SAW Filter
Part Number
Package
Application
Last Modified
802-RF902.5M-C
.
TYPE :
3.0 x 3.0 SMD
Wireless Communication
Mar. 2, 2007
Wireless, RF SAW Filter
PART NUMBER :
802-RF902.5M-C
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency (Fo)
Maximum Insertion Loss
Attenuation:
Condition
-
894.0~ 911.0 MHz
Fo-200.0~ Fo-50.0MHz
Fo+42.8~ Fo+60.0MHz
Fo+60.0~ Fo+200.0MHz
Source Impedence (single ended)*
Load Impendance (single ended)*
Amplitude Ripple
Maxium DC Voltage
VSWR
Maximum Input Power
Operating Temperature
* No Matching Network
-
-
894.0~ 911.0 MHz
-
894.0~ 911.0 MHz
-
-
Minimum
-
-
50
42
50
-
-
-
-
-
-
-30
Typical
902.5
2.7
57
47
57
50
50
0.6
-
1.6
-
-
Maximum
-
3.5
-
-
-
-
-
1.5
0
2.0
10
+65
ohm
ohm
dBp-p
V
-
dBm
ºC
dB
Units
MHz
dB
.
PACKAGE OUTLINE
(mm)
PIN LAYOUT
A
B
C
D
E
F
Ground
Out
Ground
Ground
In
Ground
TEST FIXTURE
Source/ Load Impedance = 50 ohms
