Oscilent Corporation RF SAW Filter | 802-RF853.5M-A
Page 1 of 3
RF SAW Filter
Part Number
Package
Application
Last Modified
802-RF853.5M-A
.
TYPE :
3.0 x 3.0 SMD
Wireless
Jan. 01, 2007
RF SAW Filter for Wireless Communication
PART NUMBER :
802-RF853.5M-A
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency (Fo)
Maximum Insertion Loss
Stop Band Attenuation:
Condition
-
851~ 856 MHz
D.C,~ 810.0 MHz
810.0~830.0 MHz
895.0~ 915.0MHz
915.0~ 1500.0 MHz
Source Impedence (single ended)*
Load Impendance (single ended)*
VSWR
Amplitude Ripple
Maximum DC Voltage
Maximum Input Power
Operating Temperature
-
-
851.0~ 856.0 MHz
869.0~ 894.0MHz
-
-
-
Minimum
-
-
50
42
26
50
-
-
-
-
-
-
-15
Typical
853.5
2.5
60
47
30
58
50
50
1.4
0.3
-
-
-
Maximum
-
4.0
-
-
-
-
-
-
2.0
2.0
5
15
+65
ohm
ohm
-
dBp-p
V
dBm
ºC
dB
Units
MHz
dB
* No Matching Network(Ref. Testing Enviroment Circut as shown below)
.
PACKAGE OUTLINE
(mm)
PIN LAYOUT
A
B
C
D
E
F
Ground
Out
Ground
Ground
In
Ground
TEST FIXTURE
