RF SAW Filter
Part Number
Package
Application
Last Modified
802-RF1747.5M-A
.
TYPE :
3.0 x 3.0 SMD
PCN
Mar. 2, 2007
PCN, RF SAW Filter
PART NUMBER :
802-RF1747.5M-A
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency (Fo)
Maximum Insertion Loss
Attenuation:
Condition
-
1710.0~ 1785.0 MHz
DC~ 1670.0 MHz
1670.0~ 1680.0 MHz
1805.0~ 1880.0MHz
1880.0~ 4500.0 MHz
4500.0~ 5200.0 MHz
Source Impedence (single ended)*
Load Impendance (single ended)*
VSWR
Amplitude Ripple
Maximum DC Voltage
Maximum Input Power
Operating Temperature
-
-
1710.0~ 1785.0 MHz
1710.0~ 1785.0 MHz
-
-
-
Minimum
-
-
18
15
5
20
15
-
-
-
-
-
-
-20
Typical
1747.5
3.2
23
40
8
25
20
50
50
3.0
1.9
-
-
-
Maximum
-
4.0
-
-
-
-
-
-
-
3.5
2.5
0
5
+70
ohm
ohm
-
dBp-p
V
dBm
ºC
dB
Units
MHz
dB
* No Matching Network(Ref. Testing Enviroment Circut as shown below)
.
PACKAGE OUTLINE
(mm)
PIN LAYOUT
A
B
C
D
E
F
Ground
Out
Ground
Ground
In
Ground
TEST FIXTURE
