ZXCT1030

Description
Power Supply Support Circuit, Adjustable, 1 Channel, PDSO8, MO-187, MSOP-8
CategoryPower/power management    The power supply circuit
File Size216KB,10 Pages
ManufacturerZetex Semiconductors
Websitehttp://www.zetex.com/
Environmental Compliance
Related ProductsFound1parts with similar functions to ZXCT1030
Download Datasheet Parametric View All

ZXCT1030 Overview

Power Supply Support Circuit, Adjustable, 1 Channel, PDSO8, MO-187, MSOP-8

ZXCT1030 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instructionMO-187, MSOP-8
Reach Compliance Codenot_compliant
ECCN codeEAR99
Adjustable thresholdYES
Analog Integrated Circuits - Other TypesPOWER SUPPLY SUPPORT CIRCUIT
JESD-30 codeS-PDSO-G8
JESD-609 codee3
length3 mm
Humidity sensitivity level1
Number of channels1
Number of functions1
Number of terminals8
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeTSSOP
Package shapeSQUARE
Package formSMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Maximum seat height1.1 mm
Maximum supply voltage (Vsup)20 V
Minimum supply voltage (Vsup)2.2 V
surface mountYES
Temperature levelINDUSTRIAL
Terminal surfaceMATTE TIN
Terminal formGULL WING
Terminal pitch0.65 mm
Terminal locationDUAL
Maximum time at peak reflow temperature10
width3 mm
Base Number Matches1
ZXCT1030
High-side current monitor with comparator
Description
The ZXCT1030 is a high side current sense
monitor containing an internal reference and
comparator with a non-latching output. Using
this device eliminates the need to disrupt the
ground plane when sensing a load current.
The wide input voltage range of 20V down to as
low as 2.2V make it suitable for a range of
applications. Dynamics and supply current are
optimized for the processing of fast pulses,
associated with switch mode applications.
Features
Low cost, accurate high-side current sensing
Output voltage scaling
Up to 18V output
2.2V - 20V supply range
270 A quiescent current
1.5% typical accuracy
SO8 package
Voltage reference on chip
Comparator on chip
Applications
Battery chargers
Electronic fuse
DC motor control
Over current monitor
Power management
Inrush current limiting
Typical application circuit
Ordering information
Device
ZXCT1030X8TA
ZXCT1030N8TA
Issue 2 - May 2007
© Zetex Semiconductors plc 2007
Status
Last time buy
Preview
Package
MSOP8
SO8
Device
marking
ZXCT1030
ZXCT1030
1
Reel size
(inches)
7
7
Tape width
(mm)
12
12
Quantity
per reel
1000
500
www.zetex.com
