ZV952V2TA

Description
Variable Capacitance Diode, 14.2pF C(T), 12V, Silicon, Hyperabrupt, SURFACE MOUNT PACKAGE-2
CategoryDiscrete semiconductor    diode
File Size61KB,6 Pages
ManufacturerZetex Semiconductors
Websitehttp://www.zetex.com/
Environmental Compliance
Download Datasheet Parametric View All

ZV952V2TA Online Shopping

Suppliers Part Number Price MOQ In stock
ZV952V2TA - - View Buy Now

ZV952V2TA Overview

Variable Capacitance Diode, 14.2pF C(T), 12V, Silicon, Hyperabrupt, SURFACE MOUNT PACKAGE-2

ZV952V2TA Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instructionSURFACE MOUNT PACKAGE-2
Reach Compliance Codeunknown
ECCN codeEAR99
Minimum breakdown voltage12 V
ConfigurationSINGLE
Diode Capacitance Tolerance10.56%
Minimum diode capacitance ratio2
Nominal diode capacitance14.2 pF
Diode component materialsSILICON
Diode typeVARIABLE CAPACITANCE DIODE
JESD-30 codeR-PDSO-F2
JESD-609 codee3
Humidity sensitivity level1
Number of components1
Number of terminals2
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Maximum power dissipation0.25 W
Certification statusNot Qualified
minimum quality factor250
Maximum repetitive peak reverse voltage12 V
surface mountYES
Terminal surfaceMatte Tin (Sn)
Terminal formFLAT
Terminal locationDUAL
Maximum time at peak reflow temperature40
Varactor Diode ClassificationHYPERABRUPT
Base Number Matches1
950 series
SILICON LOW VOLTAGE HYPERABRUPT VARACTOR DIODES
ZV950V2, ZV952V2, ZV953V2, ZMDC953, FSD273
Device Description
A range of silicon varactor diodes for use in frequency control and
filtering. Featuring closely controlled CV characteristics, low voltage
operation and high Q. Low reverse current ensures very low phase
noise performance. These parts can be used with control voltages from
0.5V to 2.5V, making them ideal for 3 volt systems. Available in
miniature surface mount packages.
Features
Close tolerance C-V characteristics
Tuning from 0.5 to 2.5 Volts to suit 3 volt systems
Low I
R
(typically 10pA)
Excellent phase noise performance
High Q at low voltage
Miniature surface mount packages
Band selection for DAB applications - FSD273
Applications
VCXO and TCXO
Wireless communications
Pagers
Mobile radio
Digital Radio receivers
ISSUE 2 - MAY 2002
1
