527-169
EMI/RFI Banding Backshell Assembly
for Radiall 617 610-058 & -059 Connectors
527 169 M 07 A
Product Series
Basic Number
Dash No. (Table I)
Finish (Table II)
1.190 (30.2)
.440 (11.2)
.135 (3.4)
.075 (1.9)
A = Additional Jackscrew
1.160 (29.4) Length
.063
(1.6)
2.910
(1.6)
M7 x .75
(19.05)
Thread
B
A
3.030
(77.0)
1.890 (48.0)
Max
1.220 (31.0)
Standard
(See P/N
development
for Option)
.625
(15.9)
.750
(19.1)
TABLE II: FINISH OPTIONS
TABLE I:
CABLE ENTRY
Dash
A
No.
06 .375 (9.5)
07 .437 (11.1)
08 .500 (12.7)
B
.500 (12.7)
.562 (14.3)
.625 (15.9)
Symbol
B
C*
G*
J
LF
M
N
Finish
Symbol Finish
Zinc Cobalt/Dark Olive Drab
Cadmium Plate/Olive Drab
NC
Black Anodize
NF
Cadmium Plate/Olive Drab over
Anodic Hard Coat
Electroless Nickel
Gold Iridite over Cadmium Plate
T
Cadmium Plate/Bright over
over Electroless Nickel
Electroless Nickel
Cadmium Plate/Bright over
U**
Cadmium Plate/Black
Zinc-Nickel Alloy/Olive Drab
Electroless Nickel
ZN
Electroless Nickel
*Anodize finish is not suitable for EMI shielding or grounding
Cadmium Plate/Olive Drab over
applications. to corrosion resisting steel backshells and
**Applicable
Electroless Nickel
accessories. Consult factory for other available finishes.
Metric dimensions (mm) are indicated in parentheses.
© 2004 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
