PROFESSIONAL LED INDICATORS Ø12.7mm Mounting
FEATURES
Robust bright nickel plated brass housing
514 SERIES
PACK QUANTITY = 10 PIECES
Sealed to IP67
Raised profile styling
Suitable for high vibration applications
Internal reverse protection diode fitted as standard in all
voltage models.
SPECIFICATION
Ordering Information & Typical T
echnical Characteristics (T
a = 25°C)
Mean Time Between Failure = 100,000 Hours.
PART NUMBER
COLOUR
Luminous intensity figures refer to the unmodified discrete LED.
VOLTAGE
CURRENT
LUMINOUS
WAVE
OPERATING
STORAGE
LENS
DC (Vdc)
Vopr
DC (mA)
lopr
INTENSITY
lv@20mA (mcd)
LENGTH
λp
(nm)
TEMP
T
opr
TEMP
T
stg
STANDARD INTENSITY
514-105-21
514-111-21
514-114-21
514-105-23
514-111-23
514-114-23
Red
Yellow
Green
Red
Yellow
Green
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
12
12
12
24-28
24-28
24-28
19
20
20
20
20
20
100
50
60
100
50
60
627
590
565
627
590
565
-40 ~ +85^
-40 ~ +85^
-40 ~ +85^
-40 ~ +85^
-40 ~ +85^
-40 ~ +85^
-40 ~ +85
-40 ~ +85
-40 ~ +85
-40 ~ +85
-40 ~ +85
-40 ~ +85
Yes
Yes
Yes
Yes
Yes
Yes
HIGH INTENSITY
514-102-04
514-102-21
514-102-23
UNITS
Red
Red
Red
Colour Diffused
Colour Diffused
Colour Diffused
1.9*
12
24-28
Vdc
20
20
20
mA
450
450
450
mcd
660
660
660
nm
-40 ~ +85^
-40 ~ +85^
-40 ~ +85^
°C
-40 ~ +85
-40 ~ +85
-40 ~ +85
°C
Yes
Yes
Yes
* = Voltage DC for 20mA product is Vf@20mA, not Vopr
Other voltages AC/DC available. Please contact our Technical Sales.
^ = Products must be derated according to the derating information
How to Order:
website: www.marl.co.uk • email: sales@marl.co.uk •
•
T
elephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
BS EN ISO 9001:2000
relating to either products or service.
for products or service.
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
Marl International reserve the right to alter without notice the specification or any conditions of supply
Approved Manufacturer
© MARL INTERNATIONAL LTD 2008 : DS 036/06
Issue 4
SAMPLES AVAILABLE
Page 1 of 3
514 Series
Mounting Hole
Dimensions in mm (Typical)
Not to scale
Anode termination indicated by red sleeve
Mounting hole to be clean and burr free
MATERIALS
Body
Brass to BS 2874 CZ121
Nickel plated to BS 1224
Nut
Brass to BS 2874 CZ121
nickel plated to BS 1224
Panel Seal
T
ermination
Viton
Brass to BS 2874 CZ108
Copper flash undercoat with silver flash finish
Lock Washer
Encapsulation
Zinc plated steel
PC5430 resin
PUSH-ON CONNECTORS
925-000-00 is brass tin plated.
Dimensions in mm (Typical)
Not to scale
For use with 514 series lamps.
TECHNICAL CHARACTERISTICS
SERIES
MAXIMUM
DISSIPATION
514
1000
mw
* = Current version
POWER
MAXIMUM
VOLTAGE
3* /1000•
Vdc
REVERSE
PANEL
NUT
MINIMUM
MIN/MAX.
THICKNESS
1.5-8.0
mm
PANEL
CUTOUT
TORQUE
1.0
Nm
MOUNTING
CENTRES
x,y=19.5
mm
MOUNTING
12.7
mm
• = Voltage version
OPTIONAL FLYING LEAD TERMINATIONS
ORDER
SUFFIX
15
15
19
19
CODE
SUPPLY
WIRE
WIRE
NO/DIAMETER
CONDUCTORS
OF
DIAMETER
INSULATION
OVER
COMMENTS
VOLTAGE
COLOUR
LENGTH
DC Products
AC Products
DC Products
AC Products
Red-anode / Black-cathode
Brown-live / Blue-neutral
Red-anode / Black-cathode
Brown-live / Blue-neutral
150mm
150mm
1000mm
1000mm
Customised
available
19/0.15mm
1.2mm
lengths
website: www.marl.co.uk • email: sales@marl.co.uk •
•
T
elephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
relating to either products or service.
for products or service.
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
Marl International reserve the right to alter without notice the specification or any conditions of supply
Approved Manufacturer
BS EN ISO 9001:2000
© MARL INTERNATIONAL LTD 2008 : DS 036/06
Issue 4
SAMPLES AVAILABLE
Page 2 of 3
DERATING INFORMATION
102, 105, 111 & 114
ALSO AVAILABLE
Part numbers also available in the 514 Series:
PART NO.
COLOUR
VOLTAGE DC
(Vdc) Vopr
514-102-22
514-102-25
514-102-72
514-102-75
514-102-76
514-105-04
514-105-22
514-105-25
514-105-55-15
514-105-72
514-105-72-19
514-105-75
514-105-76
514-105-76-15
514-111-04
514-111-22
514-111-72
514-111-72-19
514-111-75
514-111-75-19
514-111-76
514-111-77
514-114-04
514-114-20
514-114-22
514-114-55-15
UNITS
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Yellow
Yellow
Yellow
Yellow
Yellow
Yellow
Yellow
Yellow
Green
Green
Green
Green
24 Vdc
110 Vdc
24 Vac
110 Vac
230 Vac
20mA
24 Vdc
110 Vdc
130 Vdc
24 Vac
24 Vac
110 Vac
230 Vac
230 Vac
20mA
24 Vdc
24 Vac
24 Vac
110 Vac
110 Vac
230 Vac
125 Vac
20mA
5/6 Vdc
24 Vdc
130 Vdc
514-114-72
514-114-75
514-114-76
514-501-04
UNITS
Green
Green
Green
Red
PART NO.
COLOUR
VOLTAGE DC
(Vdc) Vopr
24 Vac
110 Vac
230 Vac
20mA
The products listed above illustrate all of the options available to order. These products may have custom modifications that alter
their operation beyond the generic information contained within this datasheet. Please contact sales for further information.
website: www.marl.co.uk • email: sales@marl.co.uk •
•
T
elephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
BS EN ISO 9001:2000
relating to either products or service.
for products or service.
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
Marl International reserve the right to alter without notice the specification or any conditions of supply
Approved Manufacturer
© MARL INTERNATIONAL LTD 2008 : DS 036/06
Issue 4
SAMPLES AVAILABLE
Page 3 of 3
