Micro-D Backshells
EMI, Banding, Elliptical, One Piece 507-175
17-7PH Stainless Steel Clips
attach the backshell to the
connector. These backshells accept standard and
micro
BAND-IT
®
shield termination straps.
Straight, 45° and Right Angle
elliptical backshell
provides plenty of working room for complicated wiring
situations.
Rugged One-Piece Aluminum Shell
with stainless steel
hardware, available in standard nickel plating, or choose
optional finishes.
A
B
C
D
HOW TO ORDER 507-175 EMI BACKSHELLS
Connector
Size
09
15
21
25
31
37
51
51-2
67
69
100
In.
± .010
E
Hardware Option
Omit (Leave Blank)
Fillister Head Jackscrew
Series
Top Entry
Shell Finish
E
J
M
NF
Z2
–
Chem Film
Cable Entry Code
D
Size
01
02
03
04
05
06
07
08
mm.
± 0.25
In.
± .010
E
mm.
± 0.25
507T175
(Alodyne)
Chromate
Nickel
–
Cadmium, Yellow
–
Electroless
–
Cadmium,
–
Gold
Available
on Shell
Size
09 Thru 100
15 Thru 100
21 Thru 100
25 Thru 100
31 Thru 100
37 Thru 100
37 and 100
100
F
.344
.494
.644
.744
.894
.994
1.044
1.024
8.74
12.55
16.36
18.90
21.34
25.25
26.52
26.01
.290
.290
.290
.304
.304
.304
.304
.384
7.37
7.37
7.37
7.72
7.72
7.72
7.72
9.75
G
H
–
Hex Head Jackscrew
Olive Drab
H
Side Entry
507S175
E
–
Extended Jackscrew
J
E
K
D
507E175
45°
Entry
F
–
Jackpost, Female
L
M
N
Sample Part Number
507E175
© 2006 Glenair, Inc.
www.glenair.com
M
25
CAGE Code 06324/0CA77
04
Printed in U.S.A.
E-Mail: sales@glenair.com
P
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
L-19
Micro-D
Backshells
Micro-D Backshells
EMI, Banding, Elliptical, one piece 507-175
MATERIALS (SEE oRDERING INFo FoR FINISh opTIoNS)
Shell
Clips
Jackscrews, Washers, Jackposts
B
A
B
C
D
Aluminum Alloy 6061 -T6 Per QQ-A-200, QQ-A-225 (Machined Components)
Aluminum Alloy 6061-T6 Per QQ-A-591 (A380) (Die-Cast Components)
17-7PH Stainless Steel
300 Series Stainless Steel, Passivated
E
.32 (8.1)
G
J
L
K
H
F
A
D
C
.175 (4.4)
E
F
G
H
J
K
L
M
N
P
Cable
Entry
Code
01
02
03
04
05
06
07
08
D
In.
± .010
mm.
± 0.25
In.
± .010
CONNECTOR ORDERED
SEPARATELY
#2-56 UNC THDS. 9-69 PIN
#4-40 UNC THDS. 100 PIN
CABLE ENTRY SIZES
E
mm.
± 0.25
Available
on Shell
Size
09 Thru 100
15 Thru 100
21 Thru 100
25 Thru 100
31 Thru 100
37 Thru 100
37 and 100
100
.344
.494
.644
.744
.894
.994
1.044
1.024
8.74
12.55
16.36
18.90
21.34
25.25
26.52
26.01
.290
.290
.290
.304
.304
.304
.304
.384
7.37
7.37
7.37
7.72
7.72
7.72
7.72
9.75
STANDARD
FILLISTER HEAD
JACKSCREW
CODE H
HEX HEAD
JACKSCREW
CODE F
FEMALE
JACKPOST
CODE E
EXTENDED
JACKSCREW
DIMENSIoNS
Size
09
15
21
25
31
37
51
51-2
67
69
100
A Max.
In.
mm.
.850
1.000
1.150
1.250
1.400
1.550
1.500
1.910
2.310
1.810
2.235
21.59
25.40
29.21
31.75
35.56
39.37
38.10
48.51
58.67
45.97
56.77
B Max.
In.
mm.
.370
.370
.370
.370
.370
.370
.410
.370
.370
.410
.460
9.40
9.40
9.40
9.40
9.40
9.40
10.41
9.40
9.40
10.41
11.68
In.
.565
.715
.865
.965
1.115
1.265
1.215
1.615
2.015
1.515
1.800
C
mm.
14.35
18.16
21.97
24.51
28.32
32.13
30.86
41.02
51.18
38.48
45.72
F Max.
In.
mm.
.782
.832
.882
.932
.972
.972
1.092
1.092
1.092
1.092
1.157
19.86
21.13
22.40
23.67
24.69
24.69
27.74
27.74
27.74
27.74
29.39
G Max.
In.
mm.
.970
.970
.970
.990
.990
.990
1.030
1.030
1.030
1.030
1.090
24.64
24.64
24.64
25.15
25.15
25.15
26.16
26.16
26.16
26.16
27.69
h Max.
In.
mm.
.668
.668
.668
.678
.678
.678
.698
.698
.698
.698
.723
16.97
16.97
16.97
17.22
17.22
17.22
17.73
17.73
17.73
17.73
18.36
J Max.
In.
mm.
.673
.673
.673
.700
.700
.700
.758
.758
.758
.758
.824
17.09
17.09
17.09
17.78
17.78
17.78
19.25
19.25
19.25
19.25
20.93
K Max.
In.
mm.
.851
.876
.901
.943
.963
.983
1.050
1.050
1.050
1.050
1.130
21.62
22.25
22.89
23.95
24.46
24.97
26.67
26.67
26.67
26.67
28.70
© 2006 Glenair, Inc.
www.glenair.com
CAGE Code 06324/0CA77
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
L-20
