S
AFETY
C
ERTIFIED
C
APACITORS
Johanson Dielectrics Type SC ceramic chip capacitors are
designed for AC voltage surge and lightning protection in
line-to-ground interface applications in computer network,
modem, facsimile and other equipment.
Johanson’s safety capacitor offering includes four different
case sizes and NPO and X7R dielectric materials.
These devices are surface mount ready with barrier
terminations and tape and reel packaging.
Additional information on capacitor safety ratings may be
found below. Specific certification details may be found
under each product listing on the facing page.
W
L
T
E/B
SAFETY
RATING
X2/Y3
Y3
X1/Y2
Y2
X1/Y2
VOLTAGE
RATING
250 VAC
250 VAC
250 VAC
250 VAC
250 VAC
WITHSTANDING
VOLTAGE
1,500 VAC
1,500 VAC
1,500 VAC
1,500 VAC
1,500 VAC
IMPULSE
VOLTAGE
2,500 V
N/A
5,000 V
5,000 V
5,000 V
CASE
SIZE
1808
1812
1808
2211
2220
JOHANSON
ORDERING P/N
302R29______V_E-****-SC
302S43______V_E-****-SC
502R29______V_E-****-SC
502R30______V_E-****-SC
502S47______V3E-****-SC
X Capacitors are defined as suitable for use in situations where failure of the capacitor would not lead to danger of electric shock.
Y Capacitors are defined as suitable for use in situations where failure of the capacitor could lead to danger of electric shock.
NOW AVAILABLE
with Polyterm
®
soft termination option for
H
OW TO
O
RDER
S
AFETY
C
ERTIFIED
302
IMPULSE
VOLTAGE
302 = 3000V
502 = 5000V
demanding environments & processes. Visit our website for full details.
R29
SIZE
See Size
Chart
N
DIELECTRIC
N = NPO
W = X7R
101
CAPACITANCE
1st two digits are
significant; third digit
denotes number of
zeros; 101 = 100 pF
K
TOLERANCE
NPO: J = ± 5%
K = ± 10%
X7R: K = ± 10%
M = ± 20%
V
TERMINATION
V = Ni barrier w/
100% Sn Plating
MARKING
3 = Special (J)
4 = No marking
3
E
-
****
-
SC
TYPE
SC = Safety
Certified
TAPE MODIFIER
Code
Tape
Reel
E
Embossed
7”
Tape specifications
conform to EIA RS481
P/N written: 302R29N101KV3E-****-SC
10
www.johanson dielectrics.com
S
AFETY
C
ERTIFIED
C
APACITORS
5 pF
10 p
F
12 p
F
15 p
F
18 p
F
22 p
F
27 p
F
33 p
F
47 p
F
56 p
F
68 p
F
100
pF
120
pF
15 0
pF
180
pF
220
pF
270
pF
330
pF
470
pF
560
pF
680
pF
100
0p
120 F
0p
150 F
0p
180 F
0p
220 F
0p
270 F
0p
330 F
0p
47 0 F
0 pF
R29 / 1808
X2/Y3
L
W
T
E/B
C
INCHES
.180 ±.010
.080 ±.010
.080 Max.
.020 ±.010
.125 Max.
(mm)
(4.57 ±.25)
(2.03 ±.25)
(2.03)
(0.51±.25)
(3.18)
DIELECTRIC
NPO
X7R
STANDARDS:
EN132400:1994+A1, IEC 60384-14:1993+A1, EN 60950:1992+A1+A2+A3+A4+A11 • UL 1950, Third Edition
CERTIFICATIONS:
TUV Rheinland T72051130 & T72041946 • UL File E212609 • Semko 0026092-1 & 0003222-1
S43 / 1812
Y3
L
W
T
E/B
INCHES
.175 ±.010
.125 ±.010
.115 Max.
.025 ±.015
(mm)
(4.45 ±.25)
(3.17 ±.25)
(2.92)
(0.64±.38)
STANDARDS:
EN132400:1994+A1, IEC 60384-14:1993+A1, EN 60950:1992+A1+A2+A3+A4+A11
CERTIFICATIONS:
TUV Rheinland T72041946
R29 / 1808
X1/Y2
L
W
T
E/B
INCHES
.189 ±.010
.080 ±.010
.085 Max.
.012 ±.005
(mm)
(4.80 ±.25)
(2.03 ±.25)
(2.16)
(0.30±.13)
STANDARDS:
EN132400:1994+A2, IEC 60384-14:1993+A1 / UL60950-01, First Edition
CERTIFICATIONS:
TUV Rheinland T72041313 & T72041314 / UL File E212609-A1-UL-1
R30 / 2211
Y2
L
W
T
E/B
INCHES
.225 ±.016
.110 ±.010
.115 Max.
.020 ±.010
(mm)
(5.72 ±.40)
(2.80 ±.25)
(2.92)
(0.51±.25)
STANDARDS:
EN132400:1994+A2, IEC 60384-14:1993+A1 • UL60950-01, First Edition
CERTIFICATIONS:
TUV Rheinland T72041313 & T72041314 • UL File: E212609-A1-UL-1
S47 / 2220
X1/Y2
L
W
T
E/B
INCHES
.225 ±.010
.200 ±.010
.150 Max.
.025 ±.015
(mm)
(5.72 ±.25)
(5.08 ±.25)
(3.81)
(0.64±.38)
STANDARDS:
EN132400:1994+A2, IEC 60384-14:1993+A • UL60950-01, 3rd Edition
CERTIFICATIONS:
TUV Rheinland 2272848 • UL File: E212609-A1-UL-1
www.johanson dielectrics.com
5 pF
10 p
F
12 p
F
15 p
F
18 p
F
22 p
F
27 p
F
33 p
F
47 p
F
56 p
F
68 p
F
100
pF
120
pF
150
pF
180
pF
220
pF
270
pF
330
pF
470
pF
560
pF
680
pF
100
0p
120 F
0p
150 F
0p
180 F
0p
220 F
0p
270 F
0p
330 F
0p
470 F
0 pF
DIELECTRIC
5 pF
10 p
F
12 p
F
15 p
F
18 p
F
22 p
F
27 p
F
33 p
F
47 p
F
56 p
F
68 p
F
100
pF
120
pF
150
pF
180
pF
220
pF
270
pF
330
pF
470
pF
560
pF
680
pF
100
0p
120 F
0p
150 F
0p
180 F
0p
220 F
0p
270 F
0p
330 F
0p
470 F
0 pF
DIELECTRIC
5 pF
10 p
F
12 p
F
15 p
F
18 p
F
22 p
F
27 p
F
33 p
F
47 p
F
56 p
F
68 p
F
100
pF
120
pF
150
pF
180
pF
220
pF
270
pF
330
pF
470
pF
560
pF
680
pF
100
0p
120 F
0p
150 F
0p
180 F
0p
220 F
0p
270 F
0p
330 F
0p
470 F
0 pF
DIELECTRIC
5 pF
10 p
F
12 p
F
15 p
F
18 p
F
22 p
F
27 p
F
33 p
F
47 p
F
56 p
F
68 p
F
10 0
pF
1 20
pF
1 50
pF
18 0
pF
22 0
pF
2 70
pF
33 0
0 pF
470
pF
56 0
pF
6 80
pF
1 00
0p
12 0 F
0p
15 0 F
0p
1 80 F
0p
22 0 F
0p
2 70 F
0p
33 0 F
0p
4 70 F
0 pF
DIELECTRIC
X7R
NPO
X7R
NPO
X7R
X7R
11
