Tunable Hi-Q RF Coils—
5YN series
A. Electrical specification:
P/N
5YN201
5YN202
5YN203
5YN204
5YN205
5YN206
5YN207
5YN208
5YN209
5YN210
Pin
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Pin (1-4)
Test Freq.
(MHz)
110
110
60
60
60
25.2
25.2
25.2
25.2
25.2
L Min.
(nH)
35.5
55.1
85.1
127.0
167.9
245.0
237.0
388.0
415.0
500.0
Specification
L Nom.
L Max.
(nH)
(nH)
38.4
62.5
99.1
149.7
201.0
310.0
350.0
460.0
540.0
650.0
41.4
72.9
119.1
180.4
246.9
357.0
400.0
510.0
620.0
760.0
Q (Min.)
@L Nom.
DCR
(mΩ MAX)
30
40
50
55
60
75
80
85
90
85
75.0
73.0
98.0
105.0
120.0
155.0
170.0
185.0
195.0
210.0
B. Mechanical dimensions: (Unit: mm)
+0.15
ø0.4-0.05
3
5.2-0.1
+0.3
5.2-0.1
3.5±0.3
4
C. General Information:
1.
2.
3.
4.
5.
Can be tunable.
Excellent temperature coefficient.
For high frequency operation up to GHz.
Unique winding configuration and custom magnet wire.
RoHS
compliant.
Variable RF Coils—5YNxxx
parts
+0.3
5.8±0.3
2
6
1
3.0±0.3
3.5±0.3
Bottom View
5YNxxx series
Patent Pending
Rev. A
Jan. 01, 2006. Page: 1 of 1
