Product Bulletin OPB960
February 1998
Photologic™ Slotted Optical Switches
Types OPB960, OPB970 Series
Features
•
Choice of mounting configuration
•
Choice of aperture
•
Choice of output configuration
•
Choice of opaque or IR transmissive
shell material
•
Data rates to 250 kBaud
•
0.320”lead spacing for PC board
mount
Absolute Maximum Ratings
(T
A
= 25
o
C unless otherwise noted)
Supply Voltage, V
CC
(Not to exceed 3 sec.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10V
Storage Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40
o
C to +85
o
C
Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40
o
C to +70
o
C
Lead Soldering Temperature [1/16 inch (1.6mm) from case for 5 sec. with soldering
iron] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
o
C
(1)
Input Diode Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mW
(2)
Output Photologic™ Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200mW
(3)
Total Device Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300mW
(4)
Voltage at Output Lead (Open Collector Output) . . . . . . . . . . . . . . . . . . . . . . . . . . 35V
Diode Forward D.C. Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40mA
Diode Reverse D.C. Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2V
Notes:
(1) RMA flux is recommended. Duration can be extended to 10 sec. max. when flow soldering.
(2) Derate linearly 2.22mW/
o
C above 25
o
C.
(3) Derate linearly 4.44mW/
o
C above 25
o
C.
(4) Derate linearly 6.66mW/
o
C above 25
o
C.
(5) The OPB960/OPB970 series are terminated with .020" square leads designed for printed
circuit board mounting.
(6) Normal application would be with light source blocked, simulated by I
F
= 0mA.
(7) All parameters tested using pulse technique.
Description
The OPB960 and OPB970 series of
Photologic™ Photo Integrated Circuit
Switches provide optimum flexibility for
the design engineer. Buidling from a
standard housing with a .125”wide slot,
the user can specify (1) type and polarity
of TTL output, (2) discrete shell material,
(3) aperture width, and (4) type of
mounting configuration. Available with
24” 26AWG wire leads as
,
OPB980/OPB990 series.
The electrical ouput can be specified as
either ttL totem pole or TTL open
collector. Either may be supplied with
inverter or buffer output polarity. All have
added stability of a built-in hysteresis
amplifier.
Housing
All housings are an opaque grade of injection-molded plastic to minimize the
assembly’ sensitivity to ambient radiation, both visible and near-infrared. Discrete
s
shells (exposed on the parallel faces inside the device throat) are either IR
transmissive plastic for applications where aperture contamination may occur or
opaque plastic for maximum protection against ambient light.
Optek reserves the right to make changes at any time in order to improve design and to supply the best product possible.
1-OTWO
Types OPB960, OPB970 Series
Electrical Characteristics
(T
A
= -40
o
C to +70
o
C unless otherwise noted).
SYMBOL
Input Diode
V
F
I
R
V
CC
PARAMETER
MIN
TYP MAX UNITS
1.7
100
V
µA
V
TEST CONDITIONS
I
F
= 20 mA, T
A
= 25
o
C
V
R
= 2.0 V, T
A
= 25
o
C
Forward Voltage
Reverse Current
Operating D.C. Supply Voltage
Low Level Supply Current:
Buffered Totem-Pole Output
Buffered Open-Collector Output
Inverted Totem-Pole Output
Inverted Open-Collector Output
High Level Supply Current:
Buffered Totem-Pole Output
Buffered Open-Collector Output
Inverted Totem-Pole Output
Inverted Open-Collector Output
Low Level Output Voltage:
Buffered Totem-Pole Output
Buffered Open-Collector Output
Inverted Totem-Pole Output
Inverted Open-Collector Output
High Level Output Voltage:
Buffered Totem-Pole Output
2.4
4.75
Output Photologic
®
Sensor
5.25
I
CCL
15
15
mA
mA
V
CC
= 5.25 V, I
F
= 0 mA
(6)
V
CC
= 5.25 V, I
F
= 15 mA
I
CCH
15
15
mA
mA
V
CC
= 5.25 V, I
F
= 15 mA
V
CC
= 5.25 V, I
F
= 0 mA
(6)
V
OL
0.4
0.4
V
V
V
CC
= 4.75 V, I
OL
= 12.8 mA
I
F
= 0 mA
(6)
V
CC
= 4.75 V, I
OL
= 12.8 mA
I
F
= 15 mA
(6)
V
CC
= 4.75 V, I
OH
= -800
µA
I
F
= 15 mA
V
CC
= 4.75 V, I
OH
= -800
µA
I
F
= 0 mA
(6)
V
CC
= 4.75 V, V
OH
= 30 V,
I
F
= 15 mA, T
A
= 25
o
C
V
CC
= 4.75 V, V
OH
= 30 V,
I
F
= 0 mA, T
A
= 25
o
C
V
CC
= 5.0 V, T
A
= 25
o
C
V
CC
= 5.0 V
V
OH
Inverted Totem-Pole Output
High Level Output Current:
Buffered Open-Collector Output
I
OH
Inverted Open-Collector Output
I
F
(+)
I
F
(+)/I
F
(-)
I
OS
LED Positive-Going Threshold Current
Hysteresis
Short Circuit Ouput Current:
Buffered Totem-Pole Ouput
“ Series
11”
Inverted Totem-Pole Ouput
“ Series
11”
t
r
, t
f
t
PLH
, t
PHL
Output Rise Time, Output Fall Time
Propagation Delay Low-High & High-Low
-15
2.0
-60
2.4
V
V
100
100
15
µA
µA
mA
mA
V
CC
= 5.25 V, I
F
= 15 mA
Ouput = GND
V
CC
= 5.25, I
F
= 0mA
Output = GND
-15
70
5.0
-60
ns
µs
V
CC
= 5.0 V, T
A
= 25
o
C
I
F
= 0 or 15 mA
R
L
= 8 TTL (Totem Pole)
R
L
= 360Ω (Open Collector)
Optek Technology, Inc.
1215 W. Crosby Road
Carrollton, Texas 75006
2-OTWO
(972) 323-2200
Fax (972) 323-2396
