WDC-R-A-B-8: DescriptionWavelength Division Mux/Demux, 1525nm Min, 1543nm Max, LC/SPC Connector; CategoryWireless rf/communication Optical fiber; File Size228KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

WDC-R-A-B-8 Overview

Wavelength Division Mux/Demux, 1525nm Min, 1543nm Max, LC/SPC Connector

WDC-R-A-B-8 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Connection Type	LC/SPC CONNECTOR
Fiber optic equipment types	WAVELENGTH DIVISION MUX/DEMUX
Fiber type	SMF-28
Maximum operating temperature	65 °C
Minimum operating temperature
Maximum operating wavelength	1543 nm
Minimum operating wavelength	1525 nm
Nominal operating wavelength	1534 nm
Base Number Matches	1

Preview

Download Datasheet

View All

WDM

C Band Red/Blue Pass FWDM

Parameter

Operating Wavelength Range (Pass Band)

Operating Wavelength Range (Reflect Band)

Insertion Loss (Pass Band)

Insertion Loss (Reflect Band)

Isolation (Pass Band)

Isolation (Reflect Band)

Ripple (Pass Band)

Return Loss

Directivity

PDL

PMD

Maximum Power Handling

Operating Temperature

Storage Temperature

Package Dimension

Bare Fiber (B)

900 μm loose tube (L)

Specification

1525-1542.54 nm or 1547.3-1565 nm

1547.3-1565 nm or 1525-1542.54 nm

≤ 1.0 dB

≤ 0.5 dB

≥ 25 dB

≥ 12 dB

≤ 0.3 dB

≥ 50 dB

≥ 55 dB

≤ 0.1 dB

≤ 0.1 ps

300 mW

0° C ~ + 65° C

- 40° C ~ + 85° C

5.5 mm () x 35 mm (L)

5.5 mm () x 39 mm (L)

Note 1: All values specified are without connectors.

Note2: Higher performance specifications are available upon request.

Note3: Fiber Type – Corning SMF-28e.

Note4: Over operating temperature, all SOP.

W D C

-

R: red band reflect

B: blue band reflect

-

Fiber Length

A: 1 meter

B: 1.5 meter

S: Special

-

Pigtail Style

(=Package style)

B: bare fiber

L: 900 μm loose tube

-

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

www.lightel.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
