INIATURE
M
INIATURE
F
USEHOLDERS
Holder / No. 813
Not for new designs - refer to No. 862
Specifications
PC Mount, Shocksafe
an
5x20mm / 6.3x32mm Fuses
S t
IEC
d a r d
60127-6
Fuse carrier inserted Bayonet-joint
max. 0,2
45,7
UL 512
CSA C22.2. No.39
Approvals
5,5
1,65
Mounting
Horizontal / 2-Pin
Stud
Printed circuit board
(2) Solder pins 0.5mm x 1.1mm and plastic stud
IP 40 (IEC 60529)
PC2 (IEC 60127-6)
Holder/Cap:
Metal Parts:
Protection Class & Category
0,5
10
15
7,9
5,7
2 -0,05
Stud
2 +0,1
17,8
10
1,3 +0,1
17,8
Materials
Holes in the printed circuit board: 1,3 +0,1
Cap / No. 815
Slot for screwdriver
Terminals:
0,5
Black Thermoplastic
Polyamide PA 6.6, UL94 V-0
Copper alloy,
corrosion protected
Solderable, tinned
13,8
1,1 +0,1
Electrical Data (23ºC)
Bayonet-connector-nose
Rated Voltage: 250V
Rated Current: 6.3A (VDE/SEMKO)
16A (UL/CSA)
Rated Power: 1.6W (813+815 - VDE/SEMKO)
2.5W (813+816 - VDE/SEMKO)
-25ºC to +70ºC (consider de-rating)
-25ºC/+70ºC/21 days (IEC 60068-2-1...3)
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days - 95%
24 cycles at 15 min. each (IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
≤
5mΩ
Temperature
Operating Temperature
7
∅
9,2
Test
Climatic Test
1,5
max. 34
1,2
For 5x20mm Fuses
Stock Conditions
Vibration Resistance
Cap / No. 816
Slot for screwdriver
Bayonet-connector-nose
Contact Resistance
Dielectric Strength
> 1.5 kV
∅
9,2
Impulse Voltage
7
4 kV, 50 Hz, 1 min., dry
> 10
3
MΩ (500 VDC, 1 min.)
235ºC, 3 sec. (Wave)
350ºC, 1 sec. (Soldering Iron)
260ºC, 5 sec. (IEC 60068-2-20)
Conducting path - 0.2mm
2
813, 250V, Approvals
5.8g (Holder) / 2.5g (Cap)
For 6.3x32mm Fuses
1,5
max. 33,8
1,2
Insulation Resistance
Solderability
Order Information
Packaging
Bulk (100 pcs.)
Holder
Cap, 5x20mm
Cap, 6.3x32mm
No. 813 0000 000
No. 815 0000 000
No. 816 0000 000
Soldering Heat Resistance
Minimum Cross Section
Marking
Order Numbers
Unit Weight
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
