400-015
TAG
®
Ring Backshell
with Strain Relief
Self-Locking Rotatable Coupling - Split Shell
400 F D 015 M 16 06 L
40
CONNECTOR
DESIGNATORS
Product Series
Connector
Designator
Angle and Profile
C = Ultra-Low Split 90
D = Split 90
F = Split 45
H
(Table III)
Strain Relief Style (F, G, L)
Cable Entry (Table IV, V)
Shell Size (Table I)
Finish (Table II)
Basic Part No.
M
(Table III)
K (Table III)
A-F-H-L-S
SELF-LOCKING
ROTATABLE
COUPLING
A Thread
(Table I)
F
(Table III)
G (Table III)
E Typ.
(Table I)
Ground
Spring
Anti-
Rotation
Device
(Typ.)
Split 45°
Cable
Entry
J
(Table
Max
III)
Wire
Bundle
(Table III,
Note 1)
L
(Table
III)
N (Table IV)
P
(Table V)
1.00 (25.4)
Max
Split 90°
Ultra Low-
Profile Split
90°
STYLE L
Light Duty
(Table V)
.850 (21.6)
Approx.
STYLE 2
(See Note 1)
STYLE F
Light Duty
(Table V)
.416 (10.5)
Approx.
Cable
Range
STYLE G
Light Duty
(Table IV)
.072 (1.8)
Approx.
Cable
Entry
P
N
Cable
Range
P
© 2005 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 40 - Page 20
with Strain Relief
Self-Locking Rotatable Coupling - Split Shell
See inside back cover
fold-out or pages 13 and
14 for Tables I and II.
TABLE III: DIMENSIONS
Shell
Size
08/09
10/11
12/13
14/15
16/17
18/19
20/21
22/23
24/25
F
Max
.596 (15.1)
.656 (16.7)
.716 (18.2)
.776 (19.7)
.836 (21.2)
.906 (23.0)
.976 (24.8)
1.036 (26.3)
1.096 (27.8)
G
Max
1.500 (38.1)
1.560 (39.6)
1.630 (41.4)
1.660 (42.2)
1.760 (44.7)
1.820 (46.2)
1.880 (47.8)
1.940 (49.3)
2.000 (50.8)
H
Max
.836 (21.2)
.906 (23.0)
.966 (24.5)
1.026 (26.1)
1.086 (27.6)
1.156 (29.4)
1.216 (30.9)
1.276 (32.4)
1.336 (33.9)
J
Max
1.440 (36.6)
1.500 (38.1)
1.570 (39.9)
1.600 (40.6)
1.700 (43.2)
1.760 (44.7)
1.820 (46.2)
1.880 (47.8)
1.940 (49.3)
K
Ref
.496 (12.6)
.426 (10.8)
.426 (10.8)
.436 (11.1)
.576 (14.6)
.796 (20.2)
.796 (20.2)
.696 (17.7)
.696 (17.7)
L
Max
2.060 (52.3)
2.220 (56.4)
2.220 (56.4)
2.290 (58.2)
2.340 (59.4)
2.370 (60.2)
2.370 (60.2)
2.520 (64.0)
2.520 (64.0)
Function C
M
Max Wire
Max
Bundle
.837 (21.3) .250 (6.4)
.887 (22.5) .375 (9.5)
.887 (22.5) .375 (9.5)
.987 (25.1) .500 (12.7)
1.137 (28.9) .625 (15.9)
1.337 (34.0) .625 (15.9)
1.337 (34.0) .625 (15.9)
1.337 (34.0) .750 (19.1)
1.337 (34.0) .750 (19.1)
TABLE IV: CABLE ENTRY
Dash
N
Cable Entry
No.
Max
Max
.545 (13.8)
02
.250 (6.4)
03
.670 (17.0)
.375 (9.5)
04
.795 (20.2)
.500 (12.7)
05
.920 (23.4)
.625 (15.9)
06
1.045 (26.5)
.750 (19.1)
07
1.170 (29.7)
.875 (22.2)
08
1.295 (32.9)
1.000 (25.4)
1.420 (36.1)
09
1.125 (28.6)
10
1.670 (42.4)
1.250 (31.8)
Dash
No.
02
03
04
05
06
07
08
09
10
TABLE V: CABLE ENTRY
P
Cable
Max
Min
.968 (24.6)
.125 (3.2)
1.046 (26.6)
.250 (6.4)
1.156 (29.4)
.250 (6.4)
1.218 (30.9)
.375 (9.5)
1.343 (34.1)
.500 (12.7)
1.468 (37.3)
.625 (15.9)
1.593 (40.5)
.625 (15.9)
1.718 (43.6)
.750 (19.1)
1.843 (46.8)
.875 (22.2)
Range
Max
.250 (6.4)
.375 (9.5)
.500 (12.7)
.625 (15.9)
.750 (19.1)
.875 (22.2)
1.000 (25.4)
1.125 (28.6)
1.250 (31.8)
1. When maximum cable entry (page 21) is exceeded, Style 2 will be supplied (not available in
Function C). Dimensions F, G, H and J will not apply. Please consult factory.
2. Metric dimensions (mm) are indicated in parentheses.
3. Cable range is defined as the accommodations range for the wire bundle or cable.
Dimensions shown are not intended for inspection criteria.
4. Angular function "C", low-profile split elbow, not available with "S" connector designator.
© 2005 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 40 - Page 21
40
400-015
TAG
®
Ring Backshell
