DIW1112

Description
DC-DC Regulated Power Supply Module, PLASTIC, DIP-23/12
CategoryPower/power management    The power supply circuit
File Size263KB,8 Pages
ManufacturerDelta Electronics
Download Datasheet Parametric View All

DIW1112 Overview

DC-DC Regulated Power Supply Module, PLASTIC, DIP-23/12

DIW1112 Parametric

Parameter NameAttribute value
Parts packaging codeDIP
package instructionPLASTIC, DIP-23/12
Contacts23/12
Reach Compliance Codecompliant
ECCN codeEAR99
Analog Integrated Circuits - Other TypesDC-DC REGULATED POWER SUPPLY MODULE
JESD-30 codeR-PDMA-T12
Number of terminals12
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formMICROELECTRONIC ASSEMBLY
Certification statusNot Qualified
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationDUAL
Base Number Matches1
FEATURES
Efficiency up to 81%
Industry standard form factor and pinout
Size:
31.8 x20.3 x10.2mm (1.25” x0.80” x0.40”)
Input: 5V, 12V, 24V, 48V (2:1)
Output: 3.3, 5, 12, 15,
±5, ±12, ±15
Low ripple and noise
1500V isolation
UL 94V-0 Package Material
ISO 9001 and ISO14001 certified
manufacturing facility
CSA 60950-1 Recognized
Delphi DIW1100 Series DC/DC Power
Modules: 5, 12, 24, 48Vin, 3W DIP
The Delphi DIW1100, 5V, 12V, 24V, and 48V 2:1 wide input, single or
dual output, DIP form factor, isolated DC/DC converter is the latest
offering from a world leader in power systems technology and
manufacturing
Delta Electronics, Inc. The DIW1100 series operate
from 5V, 12V, 24V, or 48V (2:1) and provides 5V, 12V, or 15V of
single output and
±
12V, or
±
15V of dual output in an industrial
standard, plastic case encapsulated DIP package (body size: 1.25"x
0.80”x0.40”). This series provides up to 3W of output power with
1500V isolation and a typical full-load efficiency up to 81%. With
creative design technology and optimization of component
placement, these converters possess outstanding electrical and
thermal performance, as well as extremely high reliability under
highly stressful operating conditions.
OPTIONS
APPLICATIONS
Industrial
Transportation
Process/ Automation
Telecom
Data Networking
DATASHEET
DS_DIW1100_12032008
