FEATURES
APPLICATIONS
Small size
–
Low ESR
–
Good Pulse Capabilities
–
Stable
with Frequency and Temperature
General Purpose
–
Switching Power Supplies
–
Blocking
–
Coupling
–
AC Applications (Not across the Line)
-55°C to +105°C
+10% at 1 kHz, 25°C +5%
optional
WVDC
100
250
400
630
1000
VAC
63
200
220
250
300
For T>+85°C , The voltage must be decreased by 1.5% per °C
Frequency
C<0.1uF 0.1uF<C<1uF
1uF<C<3uF
3uF<C<5uF
C>5uF
(kHz)
1
0.1%
0.1%
0.1%
0.1%
0.1%
100
0.4%
0.7%
1.2%
1.8%
2.8%
Insulation
Capacitance
Resistance
<0.33μF
30000 MΩ
>0.33μF
10000 MΩxμF
2000 Hours, +85C with 125% of rated voltage
Capacitance Change
<3% of initially measured value
Dissipation Factor
<0.001 at 1kHz and 25°C
Insulation Resistance
>50% of maximum specified value
56 days at40°C with 90 to 95%RH, +40°C and no voltage applied
Capacitance Change
<3% of initially measured value
Dissipation Factor
<0.001 at 1kHz and 25°C
Insulation Resistance
>50% of maximum specified value
<1 nano‐Henry per mm of body length and lead length
<0.5% after 2 years at 40°C
‐200 ppm/°C, +100ppm/°C
Terminal to Terminal
160% of rated VDC or VAC applied for 2 Seconds and 25°C
Polypropylene
Metallized film
Flame Retardant epoxy resin (UL94V0)
Lead free tinned copper leads
L MAX
S+1.0
G MAX
d +0.05
12
10
1.5
0.6
18.5
15
1.5
0.8
26
22.5
1.5
0.8
31
27.5
1.5
0.8
Operating Temperature Range
Capacitance Tolerance
Peak, AC voltage (50/60 Hz)
Dissipation Factor (MAX) 25°C
Insulation Resistance
@25°C (<70% RH)for 1 minute at
100VDC applied
Load Life
Damp Heat test
Self Inductance
Capacitance Drift Factor
Capacitance Temperature
Coefficient
Dielectric Strength
Dielectric
Construction
Coating
Leads
