SGP400DZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> SGP400DZ

SGP400DZ: DescriptionSWITCHING CONTROLLER, 68kHz SWITCHING FREQ-MAX, PDIP8, LEAD FREE, DIP-8; CategoryPower/power management The power supply circuit; File Size1MB，16 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

SGP400DZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SGP400DZ	-	-	View	Buy Now

SGP400DZ Overview

SWITCHING CONTROLLER, 68kHz SWITCHING FREQ-MAX, PDIP8, LEAD FREE, DIP-8

SGP400DZ Parametric

Parameter Name	Attribute value
Parts packaging code	DIP
package instruction	LEAD FREE, DIP-8
Contacts	8
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	20 V
Minimum input voltage	8.5 V
Nominal input voltage	15 V
JESD-30 code	R-PDIP-T8
length	9.271 mm
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Maximum seat height	5.334 mm
surface mount	NO
Switch configuration	SINGLE
Maximum switching frequency	68 kHz
Temperature level	OTHER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	7.62 mm
Base Number Matches	1
