Barrier Strips
Dual Barriers
0.375" PITCH
SERIES JC6
P
HYSICAL
P
ROPERTIES
H
OUSING
M
ATERIAL
:
Polypropylene
F
LAMMABILITY
:
UL94V-0
C
OLOR
:
Black
T
ERMINAL
T
ERMINALS
:
Bright acid-tin over copper alloy
S
CREWS
:
#6-32 steel, zinc plating with clear
chromate coating. Wire clamping screw stan-
dard.
JC6-P107-03
M
ECHANICAL
P
ITCH
(T
ERMINAL
S
PACING
):
0.375"
R
ECOMMENDED
PCB H
OLE
D
IA
.:
1.8mm (.073")
E
LECTRICAL
P
ROPERTIES
M
AXIMUM
C
URRENT
:
20A
O
PERATING
V
OLTAGE
:
300V
W
IRE
R
ANGE
:
12-22 AWG
O
RDERING
I
NFORMATION
E
NVIRONMENTAL
P
ROPERTIES
O
PERATING
T
EMPERATURE
R
ANGE
:
105°C max.
JC6 - P 1 07 - 06
A
A
B
C
D
E
Series
JC6
= Dual-Barrier, 0.375" Centers
Terminal Style
P
= Printed Circuit Pin (available with 1,2 block style)
T
= Solder Turret
Q
= Quick Connect
W
= Solderless Wrap
Block Style
1
= Flat, all positions filled
2
= Flat, end mounting feet (required for cover option)
3
= Insulating turret, end mounting feet with holes
(required for cover option)
4
= Insulating turret, all positions filled
Screw Hardware
07
= Steel binding combo head screws
08
= Steel clamp-plate combo head screws (standard)
No. of Circuits
(Not positions)
02
through
16
B
C
Retaining Clips
Retaining Clips
clips fit around
Spring metal retaining
insulating barrel to provide permanent
insulating
Spring metal retaining clips fit around
mounting
provide permanent mounting of blocks
barrel to
of blocks to panels without
the need
without the need for
Use two
holes.
to panels
for mounting holes.
mounting
per block. Catalog #
JC/BC-Retaining.
Use two per block. Catalog # JC/BC-Retaining.
Bottom view
D
E
®
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in inches.
98
Barrier Strips
Dual Barriers
0.375" PITCH
SERIES JC6
TERMINALS
2
3
4
5
6
7
8
9
10
11
12
13
14
15
A
TERMINALS
16
17
18
19
20
21
22
23
24
25
26
27
28
A
P. C.
Pin
(.375) 9,5
(.750) 19,1
(1.125) 28,6
(1.500) 38,1
(1.875) 47,6
(2.250) 57,1
(2.625) 66,7
(3.000) 76,2
(3.375) 85,7
(3.750) 95,2
(4.125) 104,8
(4.500) 114,3
(4.875) 123,8
(5.250) 133,3
(5.625) 142,9
(6.000) 152,4
(6.375) 161,9
(6.750) 171,4
(7.125) 181,0
(7.500) 190,5
(7.875) 200,0
(8.250) 209,6
(8.625) 219,1
(9.000) 228,6
(9.375) 238,1
(9.750) 247,6
(10.125) 257,2
19,0
(.75)
L = A+
19,0
(.750)
5,1
(.20)
0,8
(.032)
Wire
Wrap
Insulated
W. W.
20,3
(.80)
1,5
(.06)
1,5
(.06)
A
15,9
(.63)
Solder
Turret
9,5
(.375)
Typ.
5,5
(.22)
Insulated
S. T.
Optional End
Mounting Bushing
6-32 Wire Clamping
Screw (Std)
1,5
(.06)
8,0
(.315)
14,2
(.56)
3,8
(.15)
15,5
(.61)
2,8
.11
17,8
(.70)
2,8
(.11)
11,5
(.46)
7,9
(.31)
1,3
(.05)
0,8
Typ.
(.032)
Quick
Connect
Insulated
Insulated
(Quick
Q. C.
Connect)
7,9
(.31)
Dia.
Insulated Feed-Thru
1,8
(.073)
Dia.
8,3
(.328)
17,3
(.68)
Dia.
18,5
(.76)
9,5
(.375)
Typ.
3,8
(.150) Dia.
#6 Screw
Clearance
6,3
(.25)
6,3
(.25)
7,9
(.312)
PRINTED CIRCUIT BOARD MOUNTING PANEL LAYOUT
®
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in inches.
99
