INIATURE
M
INIATURE
F
USEHOLDERS
Holder / No. 834
mount,
PCB mount , vertical
for 5x20 mm Fuses
max. 0,2
Specifications
Packaging
0
Karton (100 pcs.)
Ø 15
Einsatzträger eingesetzt
Fuse-carrier inserted
Standard
Renkverschluß
Bayonet-joint
IEC 60127-6
UL 512
CSA C22.2. No.39
Approvals
12,7
Ø 12,7
32,6
12,7
Mounting
(2) Solder pins 0.5mm x 1.1mm
IP 40 (IEC 60529)
PC2 (IEC 60127-6)
Holder/Cap:
Metal Parts:
Protection Class & Category
Ø 1,3 +0,1
10 ±0,1
0,6
3
1,1
Löcher in der Leiterplatte
Holes in the printed circuit board
Leiterplatte
Printed circuit board
Materials
5
Cap / No. 835
Schlitz für Schraubendreher
Slot for screw-driver
Renkverschlußnase
Bayonet-connector-nose
Ø 9,2
1,5
Terminals:
Black Thermoplastic
Polyamide PA 6.6, UL94 V-0
Copper alloy,
corrosion protected
Solderable, tinned
Electrical Data (40ºC)
Rated Voltage: 250V
Rated Current: 6.3A (VDE/SEMKO)
16A (UL/CSA)
Rated Power: 2.5W (834+835 - VDE/SEMKO)
-25ºC to +70ºC (consider de-rating)
-25ºC/+70ºC/21 days (IEC 60068-2-1...3)
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days - 95%
24 cycles at 15 min. each (IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
≤
5mΩ
max. 20,5
Temperature
Operating Temperature
Test
Climatic Test
Type
Flush Mount Type
7
Stock Conditions
1,5
Cap/ No. 837
1,2
Vibration Resistance
Ø 9,2
Schlitz für Schraubendreher
Slot for screw-driver
Renkverschlussnase
Bayonet-connector-nose
Contact Resistance
Dielectric Strength
> 1.5 kV
Impulse Voltage
27,4
4 kV with 1,2µs/50µs
> 10
3
MΩ (500 VDC, 1 min.)
235ºC, 2 sec. (Soldering bath) (IEC 60068-2-20)
350ºC, 3 sec. (Soldering Iron) (IEC 60068-2-20)
260ºC, 5 sec. (Soldering bath) (IEC 60068-2-20)
Conducting path - 0.2mm
2
834, 250V, Approvals
3,5g (834) / 1,6g (835) / 2,2g (837)
Insulation Resistance
Solderability
7
Soldering Heat Resistance
1,2
Type
Finger Grip Type
Minimum Cross Section
Marking
Unit Weight
Order Information
Qty.
Order
Number
Series
W ebLinks
0000
00
Packaging
0
Weitere Informationen siehe:
www.wickmanngroup.com
Weitere Anwendungshinweise siehe
Fuseology:
www.wickmanngroup.com/download/
fuseologydt.pdf
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
050906
In our continuing strategy to deliver unparalleled circuit protection solutions,
technical expertise and application leadership, we proudly introduce the
WICKMANN Group and its products to the Littelfuse portfolio.
