Common Mode EMI
Suppression Inductors
Low profile or vertical mounting available
Windings balanced within one percent
For use in switching power supply input
filter circuits
Dielectric strength 1250 V
RMS
Designed with 3.0mm minimum creep
distance between windings
Electrical Specifications @ 25°C - Operating Temperature -40°C to +125°C
Rated
RMS
Current
(AMPs)
1.8
3.5
6.0
2.6
3.2
5.2
7.5
Load
VA at
RMS Line
117 V
210
400
700
300
375
600
875
220 V
420
800
1400
600
750
1200
1750
Leakage
Inductance
130kHz
(µH MIN)
130
35
12
180
90
45
25
DCR
Max. each
WDG
(Ω)
0.240
0.060
0.020
0.160
0.120
0.040
0.020
Lead Diameter
Inches
±.003
Low
Profile
0.032
0.032
0.036
0.032
0.032
0.036
0.047
Vertical
Mount
0.032
0.032
0.036
0.040
0.040
0.036
0.047
Low Profile
Part
Number
PE-62891NL
PE-62892NL
PE-62893NL
-
PE-62895NL
PE-62896NL
PE-62897NL
Vertical
Mount Part
Number
PE-62911NL
PE-62912NL
PE-62913NL
PE-62914NL
PE-62915NL
PE-62916NL
PE-62917NL
Inductance
at 1kHz
(mH MIN)
10.0
3.0
1.0
16.0
8.0
4.0
2.0
Test Level
Volts RMS
1.0 kHz
0.50
0.20
0.08
1.00
0.50
0.20
0.08
Package
Number
1
1
1
2
2
2
2
Notes:
1. Rated RMS current for 40°C rise at any input voltage.
2.
Caution
do not exceed rated RMS current ratings.
3. To order a RoHS compliant part, add the suffix “NL” to the
part number (i.e. PE-62891 becomes PE-62891NL).
Mechanical
PE-6289XNL
Schematic
NL
Package
Number
1
2
A
1.25
31,75
1.50
38,10
B
.600
15,24
.800
20,32
C
.100
25,40
1.28
32,51
D
.015
0,38
.010
0,25
E
.900
22,86
1.083
27,50
Inches
mm
.010
Unless otherwise specified, all tolerances are
±
0,25
Dimensions:
USA 858 674 8100
1
Germany 49 7032 7806 0
Singapore 65 6287 8998
Shanghai 86 21 62787060
China 86 755 33966678
Taiwan 886 3 4356768
P592.B (06/15)
pulseelectronics.com
Common Mode EMI
Suppression Inductors
Mechanical
