ZX5T851ZTA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> ZX5T851ZTA

ZX5T851ZTA: DescriptionPower Bipolar Transistor, 5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, Plastic/Epoxy, 3 Pin, SOT-89, 3 PIN; CategoryDiscrete semiconductor The transistor; File Size123KB，6 Pages; ManufacturerZetex Semiconductors; Websitehttp://www.zetex.com/; Environmental Compliance

Download Datasheet Parametric View All

ZX5T851ZTA Overview

Power Bipolar Transistor, 5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, Plastic/Epoxy, 3 Pin, SOT-89, 3 PIN

ZX5T851ZTA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	SMALL OUTLINE, R-PSSO-F3
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	COLLECTOR
Maximum collector current (IC)	5 A
Collector-emitter maximum voltage	60 V
Configuration	SINGLE
Minimum DC current gain (hFE)	20
JESD-30 code	R-PSSO-F3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal form	FLAT
Terminal location	SINGLE
Maximum time at peak reflow temperature	40
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	130 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

ZX5T851Z

60V NPN LOW SATURATION MEDIUM POWER TRANSISTOR IN SOT89

SUMMARY

CEO

= 60V : R

SAT

= 30m ; I

= 5A

DESCRIPTION

Packaged in the SOT89 outline this new 5

generation low saturation 60V NPN

transistor offers extremely low on state losses making it ideal for use in DC-DC

circuits and various driving and power management functions.

FEATURES

•

Extremely low equivalent on-resistance;

SAT

= 30mV at 6A

•

5 amps continuous current

•

Up to 20 amps peak current

•

Very low saturation voltages

•

Excellent h

characteristics up to 10 amps

SOT89

APPLICATIONS

•

Emergency lighting circuits

•

Motor driving (including DC fans)

•

Solenoid, relay and actuator drivers

•

DC-DC modules

•

Backlight inverters

•

Power switches

•

MOSFET gate drivers

PINOUT

ORDERING INFORMATION

DEVICE

ZX5T851ZTA

REEL

SIZE

7”

TAPE

WIDTH

12mm

embossed

QUANTITY PER

REEL

1000 units

DEVICE MARKING

•

851

TOP VIEW

ISSUE 2 - DECEMBER 2004

SEMICONDUCTORS
