SAW Bandpass Filter 270751B
1. Features
IF Bandpass Filter
Low-Loss Filter
Single-Ended Operation
Ceramic Surface Mount Device (SMD) Package
Maximum Storage Temperature Range : -40
℃
~ 85
℃
Electrostatics Sensitive Device (ESD)
2. Package Dimensions
13.30±0.2
10
9
8
7
7
7.62±0.1
8
9
10
6.50±0.2
11
12
ITF04A001
270751B
1
2
3
4
6
6
1.50±0.1
11
5
2.54±0.1
5
12
1.61±0.2
4
3
2
2.54±0.1
1
0.80±0.1
Pad Configuration
Package : S1365
11
5
6, 12
Input
Output
Ground
Case ground
Dimensions shown are nominal in millimeters
Other
Body : Al
2
O
3
Ceramic
Lid : Kovar, Ni Plated
Terminations : Au plating 0.3 ~ 1.0 um, Over a 1.27 ~ 8.89 um Ni Plating
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
270751B
2004-04-27
NJ3013-CS02
1/5
SAW Bandpass Filter 270751B
3. Specifications
Fo = 70 MHz
Terminating source impedance
Terminating load impedance
: 50Ω and matching network
: 50Ω and matching network
Operating temperature range : -10℃ ~ +65℃
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
40dB Bandwidth
Amplitude Ripple (Fo +/- 3.0 MHz)
Group Delay Variation (Fo +/- 3.0 MHz)
Absolute Delay
Ultimate Rejection
Temperature Coefficient of Frequency
MHz
dB
MHz
MHz
MHz
dB
nsec
usec
dB
ppm/°C
Minimum
-
-
6.9
7.5
-
-
-
-
40
-
Typical
70.0
8.6
7.1
7.6
10.0
0.6
83
1.2
43
-86
Maximum
-
10.0
-
-
10.5
1.0
120
-
-
-
Room temperature : + 25
℃
Amplitude Ripple (Fo +/- 3.2 MHz)
Group Delay Variation (Fo +/- 3.2 MHz)
dB
nsec
Minimum
-
-
Typical
0.6
90
Maximum
1.0
120
Notes :
1)
2)
3)
All specifications are based on the matching schematic shown below
All specifications are measured by Agilent Network analyzer and full 2 port calibration
Electrical margin has been built into the design to account for the variations due to temperature drift and
manufacturing tolerances
4)
All attenuation measurements are measured relative to insertion loss
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
270751B
2004-04-27
NJ3013-CS02
2/5
SAW Bandpass Filter 270751B
4. Matching Schematic
( Actual matching values may vary due to PCB layout and parasitics )
Input
50
Ω
L1
L2
Output
50
Ω
L1 = 180 nH,
L2 = 220 nH
5. Marking Configuration
ITF
1)
04A001
2)
270751B
3)
4)
1) Manufacturer name
2) Lot Number
3) Part Number
4) Pad Number 1 Index
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
270751B
2004-04-27
NJ3013-CS02
3/5
SAW Bandpass Filter 270751B
6. Typical Performance ( at +25℃ )
CH1
S 21
270751B
PRm
BW:
Cor
1
cent: 70.425447 MHz
2
Q: 7.0501
1_ loss: -8.5294 dB
9.989 304 MHz
log MAG
10 dB/
5 Nov 2003 10:06:01
1_: 0
REF -8.533 dB
0.000 000 MHz
REF=1
dB
3
4
CENTER 70.000 000 MHz
SPAN 25.000 000 MHz
CH1
CH2
PRm
Cor
S 21
S 21
270751B
WA01
log MAG
delay
1 dB/
200 ns/
5 Nov 2003 09:08:47
1_: 0
dB
REF -8.547 dB
REF 1.512 us
3_ -54.275 ns
0.000 000 MHz
REF=1
BW:
7.625 167 MHz
cent: 70.103761 MHz
1
Q: 9.1937
1_ loss: -8.5462 dB
2
6.400 000 MHz
REF=2
PRm
Cor
3
2
1
mean: 1.177 us
3
4
s.dev: 11.354 ns
p-p: 84.623 ns
Smo
2
1
CENTER 70.000 000 MHz
SPAN 12.000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
270751B
2004-04-27
NJ3013-CS02
4/5
SAW Bandpass Filter 270751B
CH1
CH2
PRm
Cor
S 21
S 21
270751B
WA01
log MAG
log MAG
1 dB/
1 dB/
5 Nov 2003 09:09:10
REF -8.546 dB
1_: 0
dB
REF -8.797 dB
3_ .1790 dB
0.000 000 MHz
REF=1
BW:
7.074 456 MHz
CH1
CH2
PRm
Cor
S 11
S 22
270751B
WA01
SWR
SWR
5 /
5 /
REF 0
REF 0
5 Nov 2003 09:05:34
1_: 1.6028
2_ 1.7985
70.000 000 MHz
cent: 70.083495 MHz
1
Q: 9.9066
1_ loss: -8.548 dB
2
3
1
2
PRm
Cor
3
4
1
70.000 000 MHz
REF=2
1
2
2
6.400 000 MHz
mean:-8.596 3 dB
s.dev: .0914 dB
p-p: .5628 dB
PRm
Cor
1
CENTER 70.000 000 MHz
SPAN 12.000 000 MHz
2
CENTER 70.000 000 MHz
SPAN 25.000 000 MHz
CH1
S 21
270751B
log MAG
1
10 dB/
5 Nov 2003 09:06:13
REF -10.53 dB
1_: 0
0.000 000 MHz
dB
CH1
CH2
REF=1
S 11
S 22
270751B
1 U FS
1 U FS
1_: 31.209
2_ 27.867
5 Nov 2003 09:05:10
-657.23 m
3.4594 nF
2.0918
4.756 nH
70.000 000 MHz
PRm
PRm
Cor
WA01
2_:-71.165 dB
70 MHz
3_:-45.347 dB
140 MHz
2
1
70.000 000 MHz
3
PRm
Cor
2
START
.010 000 MHz
STOP 400.000 000 MHz
CENTER 70.000 000 MHz
SPAN 25.000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
270751B
2004-04-27
NJ3013-CS02
5/5
