SHARP BREAKDOWN, LOW LEAKAGE
LVA REGULATOR DIODES
LVA43A - LVA100A
1
Sharper breakdown
Lower leakage current characteristics in the 4 - 1 0 volt range
NOMINAL
VOLTAGE
Vz @ Izt
(Vdc)
4.3
4.7
5,1
5.6
6.2
6.8
7.5
8.2
9.1
10.0
TEST
CURRENT
Izt
(mA)
20
10
5
MAX ZENER
IMPEDANCE
Zzt @ Izt
(OHMS)
18
15
15
40
50
50
100
100
100
100
PART
NUMBER
MAX REVERSE
LEAKAGE CURRENT
Ir
Vr
MAX NOISE
DENSITY
@
(uAdc)
4.0
4.0
0.1
(Vdc)
1.5
2.0
2.0
3.0
4.0
5.0
6.0
6,5
8.0
9.0
250 uA
4
4
4
4
4
4
4
4
4
4
LVA43A
LVA47A
LVAS1A
LVA56A
LVA62A
LVA68A
LVA75A
LVA82A
LVA91A
LVA100A
1
0,05
0,05
0.05
0.01
0.01
0.01
0.01
Package Style
Forward Voltage (Vf)
Noise Density (Nd)
Power Dissipation (Pd)
Operating Temperature (Topr)
Storage Temperature (Tstg)
Voltage Tolerance:
@ If= 200 mAdc
@ Iz = 250 uAdc
@ Ta = 25° C
Standard Device
Suffix A
Suffix B
DO-7
1.5 Vdc
4.0 uV / VHz
400 mW
-65to+ 175°C
-65 to + 200° C
±10%
±5%
±2%
Noise Density measured from 1000 to 3000 Hz.
