WT0603ML180APT datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> WT0603ML180APT

WT0603ML180APT: DescriptionRESISTOR, VOLTAGE DEPENDENT, 18V, 0.1J, SURFACE MOUNT, CHIP, 0603, LEAD FREE; CategoryPassive components The resistor; File Size83KB，3 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet Parametric View All

WT0603ML180APT Overview

RESISTOR, VOLTAGE DEPENDENT, 18V, 0.1J, SURFACE MOUNT, CHIP, 0603, LEAD FREE

WT0603ML180APT Parametric

Parameter Name	Attribute value
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Circuit maximum DC voltage	18 V
Circuit RMS maximum voltage	14 V
Maximum energy absorption capacity	0.1 J
Manufacturer's serial number	TVS0603
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR, 7 INCH
Rated power dissipation(P)	0.05 W
Resistor type	VARISTOR
surface mount	YES
Terminal location	DUAL
Terminal shape	WRAPAROUND
Base Number Matches	1

Preview

Download Datasheet

View All

ARISTORS

Transient

Multilayer Ceramic Transient

This product is not recommended

Voltage Suppressor

for new designs. Please refer to

Standard Capacity

Littelfuse series MLA.

TVS 0603 SMD

Specifications

Packaging

Material

Tape and Reel

7 inch reel (4.000 pcs.)

Body:

Terminals:

Ceramic (ZnO)

Ni/Sn plated (code “P”)

Ag/Pt/Pd non plated

(code “N” on request)

Features

Thin layer, high precise techniques

Lead free

Bi-directional clamping

Standard and low capacity

Available with Nickel/Tin end termination

Temperature

Operating Temperature

-55 to +125°C

Solderability

Applications

Dimensions (mm)

acc. to IEC 60068-2-58

235°C, 2s

260ºC, 10 sec. (IEC 60068-2-58)

280ºC, 5 sec. (IEC 60068-2-58)

<0.5ns

0.35–0.15

Circuit board and ESD, EFT

Protection of:

• I/O ports

• Keyboards

• LCD‘s

• Sensors

Soldering Heat Resistance

Time

Response Time

W ebLinks

1.60–0.15

0.90

0.80–0.15

Further infos see:

www.wickmanngroup.com

Further technical infos see technical

varistor file:

www.wickmanngroup.com/download/

techvaristor.pdf

(α

Temperature coefficient (

V) of clamping

voltage (Vc) @ specified test current

<0.01%/°C

Power dissipation

0.05W max.

Standards

IEC 61000-4-2

MIL-STD-883C

Maximum Ratings (125°C)

Type

max. cont.

working

voltage

M(DC)

M(AC)

(V)

WT0603ML050L

WT0603ML030A

WT0603ML050A

WT0603ML090A

WT0603ML120A

WT0603ML140A

WT0603ML180A

WT0603ML220A

WT0603ML260A

WT0603ML300A

5,5

3,3

5,5

9,0

12,0

14,0

18,0

22,0

26,0

30,0

4,0

2,5

4,0

6,0

9,0

11,0

14,0

17,0

20,0

25,0

Specifications (25°C)

typ.

capacitance

1KHz

typ.

(pF)

420

1260

750

340

415

280

250

310

140

120

max.

non-repetitive

surge current

(8/20

µs)

(A)

max. non-repetitive max. clamping

nominal voltage

surge energy

voltage at spec.

at 1mA (DC)

(10/1000

µs)

current

test current

(8/20

µs)

N(DC)min.

N(DC)max.

(J)

(V@A)

(V)

0,05

0,10

15,5 @

10,0 @

15,5 @

23,0 @

27,0 @

30,0 @

40,0 @

44,0 @

58,0 @

65,0 @

7,1

3,8

7,1

10,0

14,0

16,0

22,0

24,3

29,5

35,0

9,8

7,0

9,8

14,5

18,5

21,0

28,0

30,0

38,0

43,0

typ.

inductance

1MHz

typ.

(pF)

360

1080

640

300

340

240

220

270

130

110

typ.

(nH)

1,0

Order

Information

050915

Qty.

Order-

Number

Type

WT0603ML140 A

Terminal

Terminal Code Packaging

Specifications are subject

to change without notice
