WT0805ML260APT: DescriptionRESISTOR, VOLTAGE DEPENDENT, 26V, 0.3J, SURFACE MOUNT, CHIP, 0805, LEAD FREE; CategoryPassive components The resistor; File Size74KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet Parametric View All

WT0805ML260APT Overview

RESISTOR, VOLTAGE DEPENDENT, 26V, 0.3J, SURFACE MOUNT, CHIP, 0805, LEAD FREE

WT0805ML260APT Parametric

Parameter Name	Attribute value
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	STANDARD: IEC61000-4-2
Circuit maximum DC voltage	26 V
Circuit RMS maximum voltage	20 V
Maximum energy absorption capacity	0.3 J
Manufacturer's serial number	TVS0805
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR, 7 INCH
Rated power dissipation(P)	0.1 W
Resistor type	VARISTOR
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Base Number Matches	1

Preview

Download Datasheet

View All

V

ARISTORS

Transient

Multilayer Ceramic Transient

This product is not recommended

Voltage Suppressor

for new designs. Please refer to

Standard Capacity

Littelfuse series MLA.

TVS 0805 SMD

Specifications

Packaging

Material

Tape and Reel

T

7 inch reel (3.000 pcs.)

Body:

Terminals:

Ceramic (ZnO)

Ni/Sn plated (code “P”)

Ag/Pt/Pd non plated

(code “N” on request)

Features

Thin layer, high precise techniques

Lead free

Bi-directional clamping

Standard and low capacity

Available with Nickel/Tin end termination

Temperature

Operating Temperature

-55 to +125°C

Solderability

Applications

Dimensions (mm)

acc. to IEC 60068-2-58

235°C, 2s

260ºC, 10 sec. (IEC 60068-2-58)

280ºC, 5 sec. (IEC 60068-2-58)

<0.5ns

0.40–0.25

WebLinks

2.00–0.20

1.20

1.25–0.15

Circuit board and ESD, EFT

Protection of:

• I/O ports

• Keyboards

• LCD‘s

• Sensors

Soldering Heat Resistance

Time

Response Time

(α

Temperature coefficient (

α

V) of clamping

voltage (Vc) @ specified test current

<0.01%/°C

Further infos see:

www.wickmanngroup.com

Further technical infos see technical

varistor file:

www.wickmanngroup.com/download/

techvaristor.pdf

Power dissipation

0.1W max.

Standards

IEC 61000-4-2

MIL-STD-883C

Maximum Ratings (125°C)

Type

max. cont.

working

voltage

V

M(DC)

V

M(AC)

(V)

WT0805ML030A

WT0805ML050A

WT0805ML090A

WT0805ML120A

WT0805ML140A

WT0805ML180A

WT0805ML220A

WT0805ML260A

3,3

5,5

9,0

12,0

14,0

18,0

22,0

26,0

2,5

4,0

6,0

9,0

11,0

14,0

17,0

20,0

Specifications (25°C)

typ.

capacitance

1KHz

C

typ.

(pF)

4200

1950

1580

1110

1230

760

735

460

max.

non-repetitive

surge current

(8/20

µs)

I

TM

(A)

120

max. non-repetitive max. clamping

nominal voltage

surge energy

voltage at spec.

at 1mA (DC)

(10/1000

µs)

current

test current

(8/20

µs)

W

TM

V

c

V

N(DC)min.

V

N(DC)max.

(J)

(V@A)

(V)

0,30

10,0 @

15,5 @

20,0 @

25,0 @

30,0 @

40,0 @

44,0 @

58,0 @

5

3,8

7,1

10,0

14,0

16,0

22,0

24,3

29,5

7,0

9,8

14,5

18,5

21,0

28,0

30,0

38,0

typ.

inductance

1MHz

C

typ.

(pF)

4000

1700

1340

950

1050

690

620

420

L

typ.

(nH)

1,5

Order

Information

050915

Qty.

Order-

Number

Type

WT0805ML180 A

Terminal

Terminal Code Packaging

P

T

Specifications are subject

to change without notice
