251902B Overview

SAW Bandpass Filter

Preview

Download Datasheet

View All

SAW Bandpass Filter 251902B

1. Features

IF bandpass filter

High attenuation

Single-ended operation

DIP Package

Maximum Storage Temperature Range : -40

℃

~ 85

℃

Electrostatics Sensitive Device (ESD)

2. Package Dimension

12.8±0.5

5.5max 6.0max

7.6±0.2

2.5±0.2

ITF 04A001

251902B

35.1±0.5

Package : D3512

0.45±0.05

2.5±0.2

Pin Configuration

Input

Output

Ground

Case ground

Dimensions shown are nominal in millimeters

Base : Fe(SPCC), Au plating over Ni plated

Cap : Cu & Cr Alloy, Ni Plated

Termination : Kovar, Au Plated

2, 4

3, 6

I T F Co., Ltd.

102-901, Bucheon Technopark 364,

Samjeong-Dong, Ojeong-Gu, Bucheon-City,

Gyounggi-Do, Korea 421-809

Part No.

Rev. Date

Rev.

25.4±0.2

251902B

2004-06-21

NM4012-CS01

1/5
