SAW Bandpass Filter 251005B
1. Features
IF Bandpass Filter
High Attenuation
Single-Ended Operation
DIP Package
Maximum Storage Temperature Range : -40
℃
~ 85
℃
Electrostatics Sensitive Device (ESD)
2. Package Dimension
12.7±0.5
5.5max 6.0max
7.6±0.2
2.5±0.2
ITF 09A001
251005B
145-10.0M
0.45±0.05
20.3±0.5
2.5±0.2
Package : D2012
Pin Configuration
1
Input
Output
Ground
Case ground
Dimensions shown are nominal in millimeters
Base : Fe(SPCC), Au plating over Ni plated
Cap : Cu & Cr Alloy, Ni Plated
Termination : Kovar, Au Plated
5
2, 4
3, 6
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
251005B
2009-04-13
NM9022-CS01
1/5
12.7±0.2
SAW Bandpass Filter 251005B
3. Specifications
Fo = 145.0 MHz
Terminating source impedance
Terminating load impedance
: 50Ω and matching network
: 50Ω and matching network
Minimum
Typical
Maximum
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
40dB Bandwidth
Amplitude Ripple (fo ± 4.7 MHz)
Group Delay Variation (fo ± 4.7 MHz)
Absolute Delay
Ultimate Rejection
Temperature Coefficient of Frequency
MHz
dB
MHz
MHz
MHz
dB
nsec
usec
dB
ppm/°C
-
-
-
10.2
-
-
-
-
50
-
145.0
21.5
10.0
10.35
11.88
0.45
40
3.26
58
-18
-
24.0
-
-
12.0
1.0
100
-
-
-
Notes :
1)
2)
3)
All specifications are based on the matching schematic shown below
All specifications are measured by Agilent Network analyzer and full 2 port calibration at room temperature
All attenuation measurements are measured relative to insertion loss
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
251005B
2009-04-13
NM9022-CS01
2/5
SAW Bandpass Filter 251005B
4. Matching Schematic
( Actual matching values may vary due to PCB layout and parasitics )
Input
50
Ω
L1
L2
Output
50
Ω
C1
C2
L1 = L2 = 39nH
C1 = 51nH, C2 = 39nH
5. Marking Configuration
ITF
1)
09A001
2)
251005B
3)
145
4)
-10.0M
5)
1) Manufacturer name
2) Lot Number
3) Part Number
4) Center frequency
5) 1dB-Bandwidth
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
251005B
2009-04-13
NM9022-CS01
3/5
SAW Bandpass Filter 251005B
6. Typical Performance ( at +25°C )
°
CH1 S21
LOG
10 dB/ REF -21.54 dB
31 Mar 2009 05:17:32
1: 0. 0000 dB
0. 000 000 MHz
*
CH1 Markers
Cor
1
2
BW 11. 881807 MHz
:
cent : 145. 046088 MHz
Q 12. 207
:
1_
loss : -21 . 631 dB
REF=1
Hld
3
4
CENTER145. 000 000 MHz
SPAN 32. 000 000 MHz
CH1 S21
CH2 S21
LOG
LOG
1 dB/ REF -21.24 dB
1 dB/ REF -21.66 dB
31 Mar 2009 05:18:07
1: 0. 0000 dB
0. 000 000 MHz
3: . 16440 dB
9. 400 000 MHz
CH1 Markers
BW 10. 001126 MHz
:
Cor
cent : 145. 066323 MHz
Q 14. 505
:
1
2
1_
loss : -21 . 535 dB
REF=1
3
3
4
2
Cor
CH2 Markers
mean:-21 . 447 dB
s. dev : . 09430 dB
p-p : . 44200 dB
REF=2
CENTER145. 000 000 MHz
SPAN 12. 000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
251005B
2009-04-13
NM9022-CS01
4/5
SAW Bandpass Filter 251005B
CH1 S21
CH2 S21
LOG
DEL
1 dB/ REF -21.24 dB
100 ns/ REF 3.24 us
31 Mar 2009 05:18:33
1: 0. 0000 dB
0. 000 000 MHz
3: 2. 2460 ns
9. 400 000 MHz
CH1 S21
LOG
10 dB/ REF -21.54 dB
31 Mar 2009 05:17:37
1: 0. 0000 dB
0. 000 000 MHz
*
CH1Markers
BW 10. 349040 MHz
:
Cor
cent : 145. 064485 MHz
Q 14. 017
:
1
2
Hld
1_
loss : -21 . 531 dB
REF=1
Cor
1
2
CH1Markers
BW 12. 059176 MHz
:
cent : 145. 053696 MHz
Q 12. 028
:
1_
loss : -21 . 631 dB
REF=1
3
Smo
Cor
3
CH2Markers
mean: 3. 2594 us
s. dev : 8. 3434 ns
p-p : 37. 765 ns
2
4
3
REF=2
4
CENTER145. 000 000 MHz
SPAN 12. 000 000 MHz
CENTER145. 000 000 MHz
SPAN 32. 000 000 MHz
CH1 S21
LOG
10 dB/ REF -21.11 dB
31 Mar 2009 05:19:53
1: 0. 0000 dB
0. 000 000 MHz
CH1 S11
CH2 S22
SWR
SWR
2 /
2 /
REF 1.28
REF 2.666
31 Mar 2009 05:19:10
1: 1. 2805
145. 000 000 MHz
2: 2. 6659
145. 000 000 MHz
CH1Markers
2:-62 . 839 dB
145. 000 MHz
1
3:-67 . 364 dB
290. 000 MHz
REF=1
Cor
1
Cor
2
2
START . 010 000 MHz
3
STOP 500. 000 000 MHz
CENTER145. 000 000 MHz
SPAN 32. 000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
251005B
2009-04-13
NM9022-CS01
5/5
