Part Number

Search

PS2705-4-F3

Description
AC Input-Transistor Output Optocoupler, 4-Element, 3750V Isolation, PLASTIC, SOP-16
CategoryLED optoelectronic/LED    photoelectric
File Size48KB,5 Pages
ManufacturerNEC Electronics
Download Datasheet Parametric View All

PS2705-4-F3 Overview

AC Input-Transistor Output Optocoupler, 4-Element, 3750V Isolation, PLASTIC, SOP-16

PS2705-4-F3 Parametric

Parameter NameAttribute value
package instructionPLASTIC, SOP-16
Reach Compliance Codeunknown
Coll-Emtr Bkdn Voltage-Min40 V
ConfigurationSEPARATE, 4 CHANNELS
Nominal current transfer ratio100%
Maximum dark power100 nA
Maximum forward current0.05 A
Maximum insulation voltage3750 V
Number of components4
Maximum operating temperature100 °C
Minimum operating temperature-55 °C
Optoelectronic device typesAC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER
Base Number Matches1
HIGH ISOLATION VOLTAGE
AC INPUT RESPONSE TYPE
SOP MULTI PHOTOCOUPLER
FEATURES
• HIGH ISOLATION VOLTAGE
BV:3.75 k V
r.m.s.
MIN
• SOP (SMALL OUT-LINE PACKAGE)
• ISOLATED CHANNELS PER EACH PACKAGE
• AC INPUT RESPONSE
• HIGH SPEED SWITCHING
t
r
= 3
µs,
t
f
= 5
µs
TYP
• LOW COLLECTOR TO EMITTER DARK CURRENT
I
CEO
: 5 nA TYP @ T
A
= 25
°C,
V
CE
= 40 V
• TAPE AND REEL AVAILABLE
PS2705-1
PS2705-2
PS2705-4
DESCRIPTION
PS2705-1, -2 and -4 are optically coupled isolators containing
GaAs light emitting diodes and an NPN silicon phototransistor.
Each is mounted in a plastic SOP (Small Out-line Package) for
high density applications. This package has a shield effect to
cut off ambient light.
APPLICATIONS
Interface circuit for various instrumentations and control
equipment.
• AC LINE/DIGITAL LOGIC
• DIGITAL LOGIC INTERFACE
• TWISTED PAIR LINE RECEIVER
• TELEPHONE/TELEGRAPH LINE RECEIVER
• SEQUENCE CONTROLLERS
• SYSTEMS APPLICATIONS, MEASURING
INSTRUMENTS
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C)
PART NUMBER
SYMBOLS
PARAMETERS
Forward Voltage, I
F
=
±
5 mA
Junction Capacitance, V= 0, f = 1.0 MHz
Collector to Emitter Dark Current, V
CE
= 40 V, I
F
= 0
Current Transfer Ratio, I
F
=
±
5 mA, V
CE
= 5 V
CTR Ratio
2
, I
F
=
±
5 mA, V
CE
= 5 V
Collector Saturation Voltage, I
F
=
±10
mA, I
C
= 2 mA
Isolation Resistance, V
in-out
= 1.0 k V
Isolation Capacitance, V = 0, f = 1.0 MH
Z
Rise
Time
1
,
V
CC
= 5 V, I
C =
2 mA, R
L
= 100
Fall Time
1
, V
CC
= 5 V, I
C
= 2 mA, R
L
= 100
V
pF
µs
µs
10
11
0.4
3
5
2. CTR
1
= I
C1
/I
F1
, CTR
2
= I
C2
/I
F2
UNITS
V
pF
nA
%
50
0.3
100
0.1
MIN
PS2705-1, -2, -4
TYP
1.1
60
100
300
3.0
0.3
MAX
1.4
Transistor Diode
V
F
C
I
CEO
CTR
CTR
1
/CTR
2
V
CE (sat)
R
1-2
C
1-2
t
r
t
f
Notes:
1. Test Circuit for Switching Time
I
F
PULSE INPUT
1
4
V
CC
Coupled
(
PW = 100
µs
Duty Cycle = 1/10
)
2
50
3
V
OUT
R
L
= 100
4 3
8 7 6 5
16 15 14 13 12 11 10 9
I
F1
I
C1
V
CE
I
C2
I
F2
1 2
PS2705-1
1 2 3 4
PS2705-2
1 2 3 4 5
6 7 8
PS2705-4
California Eastern Laboratories
