MIL-DTL-83723
Connectors
MIL-DTL-83723/83 Series III
Filter Connector
Product Code
240-837W
MIL-DTL-83723/83 Series III Filter Receptacle
Wall Mount Receptacle
Contact Gender
P
- Pins
S
- Socket
Alternate Key Position
A, B, C, D, E, N = Normal
Capacitance
(See Table V)
B
Insert Arrangement
Per MIL-STD-1554
Termination
S
- Solder Cup
240 - 837
W
P
14-12
P
S
P
Filter Type
P
- Pi Circuit
C
- C Circuit
A
C
N
Shell Style
W
-
Wall Mount
Connector Class
(See Table I)
Flange Mounting Style
H
- Chamfered Holes
C
- Clinch Nuts (4-40 UNC)
M
- Metric Clinch Nuts (M3)
.224/.164 (5.7/4.2)
Contact Sizes 12 & 16
.194/.134 (4.9/3.4)
Contact Size 20
.904 (23.0)
Max.
.072 (1.8)
.052 (1.3)
R Thread
D
Shell I.D.
W -
Wall Mount
H
Ø
C
F
Max.
Seal
G
Max.
A (TYP)
B (TYP)
.728 (18.5)
.708 (18.0)
.50 (12.7)
E Max.
Resilient
Insert
© 2008 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
B-54
240-837W
MIL-DTL-83723/83 Series III Filter Receptacle
Wall Mount Receptacle
TABLE I: CONNECTOR CLASS
SYM
M
MT
NF
P
ZN
H2
CLASS
Environmental
Environmental
Environmental
Environmental
Environmental
Hermetic
MATERIAL
Aluminum
Aluminum
Aluminum
Stainless Steel
Aluminum
Stainless Steel
FINISH DESCRIPTION
Electroless Nickel
Nickel Fluorocarbon polymer (Ni-PTFE)
Cadmium O.D. Over Electroless Nickel
Electro-Deposited Nickel
Zinc-Nickel Over Electroless Nickel
Electroless Nickel
TABLE II: CAPACITOR ARRAY CODE
CAPACITANCE RANGE
CLASS
X*
Y*
Z*
A
B
C
D
E
F
G
PI - CIRCUIT (pF)
160,000 - 240,000
80,000 - 120,000
60,000 - 90,000
38,000 - 56,000
32,000 - 45,000
18,000 - 33,000
8,000 - 12,000
3,300 - 5,000
800 - 1,300
400 - 600
C - CIRCUIT (pF)
80,000 - 120,000
40,000 - 60,000
30,000 - 45,000
19,000 - 28,000
16,000 - 22,500
9,000 - 16,500
4,000 - 6,000
1,650 - 2,500
400 - 650
200 - 300
* Reduced DWV – Please consult factory.
TABLE III: DIMENSIONS
SHELL
SIZE
8
10
12
14
16
18
20
22
24
A
B
C
D
SHELL I.D.
E
RESILIENT
INSERT
F
MAX.
SEAL
G
MAX.
R
COUPLING
THROUGH
THREAD
4 PL
UNEF-2A
.125 (3.2)
.562-24
.116 (2.9)
.125 (3.2)
.688-24
.116 (2.9)
.125 (3.2)
.875-20
.116 (2.9)
.125 (3.2)
.938-20
.116 (2.9)
.125 (3.2)
1.062-18
.116 (2.9)
.125 (3.2)
1.188-18
.116 (2.9)
.125 (3.2)
1.312-18
.116 (2.9)
.125 (3.2)
1.438-18
.116 (2.9)
.154 (3.9)
1.562-18
.145 (3.7)
H
PANEL
CUT-OUT
.572 (14.5)
.706 (17.9)
.885 (22.5)
.946 (24.0)
1.072 (27.2)
1.197 (30.4)
1.322 (33.6)
1.447 (36.8)
1.572 (39.9)
.812 (20.6) .594 (15.1) .500 (12.7)
.937 (23.8) .719 (18.3) .560 (14.2)
1.031 (26.2) .812 (20.6) .750 (19.1)
1.125 (28.6) .906 (23.0) .810 (20.6)
1.250 (31.8) .969 (24.6) .930 (23.6)
1.343 (34.1) 1.062 (27.0) 1.060 (26.9)
1.437 (36.5) 1.156 (29.4) 1.180 (30.0)
1.562 (39.7) 1.250 (31.8) 1.310 (33.3)
1.703 (43.3) 1.375 (34.9) 1.430 (36.3)
.418 (10.6)
.290 (7.4)
.413 (10.5)
.535 (13.6)
.388 (9.9)
.530 (13.5)
.705 (17.9)
.558 (14.2)
.700 (17.8)
.774 (19.7)
.627 (15.9)
.769 (19.5)
.901 (22.9)
.772 (19.6)
.896 (22.8)
1.007 (25.6)
.860 (21.8)
1.002 (25.5)
1.132 (28.8)
.985 (25.0)
1.125 (28.6)
1.257 (31.9)
1.110 (28.2)
1.252 (31.8)
1.382 (35.1)
1.235 (31.4)
1.377 (35.0)
.394 (10.0) .562 (14.3)
.515 (13.1) .696 (17.7)
.685 (17.4) .875 (22.2)
.754 (19.2) .936 (23.8)
.881 (22.4) 1.062 (27.0)
.987 (25.1) 1.187 (30.1)
1.112 (28.2) 1.312 (33.3)
1.237 (31.4) 1.437 (36.5)
1.362 (34.6) 1.562 (39.7)
© 2008 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
B-55
