227RZS035M: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 25 V, 1000 uF, THROUGH HOLE MOUNT; CategoryPassive components capacitor; File Size104KB，3 Pages; ManufacturerIllinois Capacitor; Websitehttp://www.illinoiscapacitor.com/; Environmental Compliance

Download Datasheet Parametric View All

227RZS035M Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 25 V, 1000 uF, THROUGH HOLE MOUNT

227RZS035M Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Illinois Capacitor
package instruction	,
Reach Compliance Code	compli
ECCN code	EAR99
capacitance	220 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	12.5 mm
dielectric materials	ALUMINUM (WET)
ESR	528 mΩ
JESD-609 code	e3
leakage current	0.077 mA
length	25 mm
Manufacturer's serial number	RZS
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Radial
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	35 V
ripple current	370.5 mA
series	RZS
surface mount	NO
Delta tangent	0.07
Terminal surface	Matte Tin (Sn)
Terminal pitch	5 mm
Terminal shape	WIRE

Preview

Download Datasheet

View All

RZS

FEATURES

I

+105°C High

Frequency Radial

Lead Aluminum

Electrolytic Capacitors

For Switching Power Supplies

High Ripple Current

Low Impedance

Low ESL and ESR

100 kHz Operating Frequency Range

I

Capacitance Range 22 µF to 2,200 µF

I

Voltage Range 6.3 WVDC to 63 WVDC

I

Solvent Tolerant End Seals Standard

Aluminum Electrolytic

SPECIFICATIONS

Capacitance Tolerance

± 20% at 120Hz, 20°C

Operating Temperature Range

Dissipation Factor

120Hz, 20°C

WVDC

tan

δ

6.3

.2

-55°C to +105°C

10

.15

16

.1

25

.08

35

.07

50

.06

63

.05

Note:

For above D.F. specifications, add .02 for every

1,000 µF above 1,000 µF

Impedance Ratio

(Max.) @120Hz

WVDC

-55°C/20°C

WVDC

6.3

2.0

10

1.5

16

1.5

25

1.5

35

1.5

50

1.5

63

1.5

≤

63 WVDC

2 minutes

.01 CV or 3 µA

whichever is greater

Leakage Current

Time

2,000 hours + 105°C with rated voltage

Load Life

Capacitance change

Dissipation factor

Leakage current

≤

20% of initial measured value

≤

200% of initial specified value

≤

initial specified value

1,000 hours at +105°C with no voltage applied.

Shelf Life

Capacitance change

Dissipation factor

Leakage current

≤

20% initial readings

≤

250% of initial specified value

≤

200% of initial specified value

SPECIAL ORDER OPTIONS

•

Special tolerances: ±10% (K), -10% + 30% (Q)

®

Epoxy end seal

•

Mylar Polyester Sleeve

(See pages 33 thru 37)

•

Tape and Reel

•

Tape Ammo Pack

•

Cut, Formed, Cut and Formed and Snap In Leads

®

3757 W. Touhy Ave., Lincolnwood, IL 60712 • (847) 675-1760 • Fax (847) 673-2850 • www.illcap.com

81
