RF-11
BNC7T–J–P–HN–ST–EM1
BNC7T–J–C–GN–ST–BH3
BNC7T SERIES
BNC7T–J–P–HN–RA–BH2D
75Ω OPTIMIZED BNC JACKS & PLUGS
Mates with:
RF179, RFA6T, RFB6T
BNC7T
* Designed to meet
SMPTE 424M 3G
SDI specification.
GENDER
TYPE
PLATING
ORIENTATION
TERMINATION
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?BNC7T-TH,
www.samtec.com?BNC7T-BH or
www.samtec.com?BNC7T-EM
Shell Material:
Ni plated Brass
(-TH1, -BH1, -EM1, -EM2)
Zinc (-TH2D, -BH2D,
-EM1D, -EM2D)
Contact Material:
Copper Alloy
Insulator Material:
PTFE
Impedance:
ST = 75Ω ±2Ω
RA = 75Ω ±4Ω
Frequency Range:
0~6 GHz *
V.S.W.R:
1.45 max
Working Voltage:
500 Vrms
Dielectric Withstanding:
1500 Vrms min
Contact Resistance:
Center Contact: 1,5mΩ max
Outer Contact: 0,4mΩ max
Operating Temperature:
-65°C to +125°C
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
–J
= Jack
–P
= PCB
Mount
(25,48) 1.003
(18,11) .713
–GN
= 10µ"
(0,25µm)
Gold
contact,
100µ"
(2,54µm)
Nickel
shell
–ST
= Straight
–TH1
= Standard
Through-hole
–EM1D
= Edge Mount
Die Cast
Bulkhead/Panel
Mount for
(1,60mm)
.062" PCB
(–ST only)
–RA
= Right Angle
Bulkhead/
Panel Mount
(19,00)
.748
(9,63)
.379
DIA
(4,50) .177
–ST–TH2D
(13,50)
.531
(9,63)
.379
DIA
(4,50) .177
–ST–TH1
–TH2D
= Tall
Through-hole
(12,70)
.500
(10,92)
.430
(9,63)
.379
DIA
–ST–EM1 & –ST–EM2
(29,00) 1.142
(8,80)
.346
–BH1
= Standard
Bulkhead
Through-hole
(–RA only)
–HN
= 30µ"
(0,76µm)
Gold
contact,
100µ"
(2,54µm)
Nickel
shell
–EM2
= Edge Mount
Bulkhead/
Panel Mount for
(2,40mm)
.093" PCB
(–ST only)
(10,80)
.425
(9,63)
.379
DIA
–RA–BH2D
(24,24) .954
–BH2D
= Low Profile Die
Cast Bulkhead
Through-hole
(–RA only)
–EM2D
= Edge Mount
Die Cast
Bulkhead/Panel
Mount for
(2,40mm)
.093" PCB
(–ST only)
(4,00)
.157
(32,75) 1.289
–EM1
= Edge Mount
Bulkhead/
Panel Mount for
(1,60mm)
.062" PCB
(–ST only)
ALSO AVAILABLE
Tool for quickly installing/
uninstalling knurl nut for
BNC7T Series
Part Number:
TOOL–BNC7T–01
(18,00)
.709
(11,30)
.445
(9,63)
(10,92) .379
.430 DIA
(18,10)
.713
–RA–BH1
(26,95) 1.061
(3,00)
.118
* Lock washers & knurled nuts supplied
with Bulkhead/Panel Mount options
SPECIFICATIONS
For complete specifications
and assembly instructions see
www.samtec.com?BNC7T-CA or
www.samtec.com?BNC7T-BH
Shell Material:
Brass
Contact Material:
Brass (–P), Copper Alloy (–J)
Center Contact:
Soldered
Outer Ferrule:
Crimped
Impedance:
75Ω
Frequency Range:
0~4 GHz (–P)*, 0~3.5 GHz (–J)*
V.S.W.R:
1.3 max
Working Voltage:
500 Vrms
Dielectric Withstanding:
1500 Vrms min
Contact Resistance:
Center Contact: 3mΩ max
Outer Contact: 2mΩ max
Insulator Resistance:
5,000 MΩ min
Operating Temperature:
-65°C to +125°C
BNC7T
* Designed to meet
SMPTE 424M 3G
SDI specification.
GENDER
TYPE
PLATING
ORIENTATION
TERMINATION
= Plug
–P
–J
–C
= Cable
–GN
= 10µ" (0,25µm)
Gold on contact,
Nickel on outer
contact and shell
–ST
= Straight
–CA3
= RG 179 Cable
(–P only)
–CA6
= RG 6 or
Belden
1694A Cable
(–P only)
= Jack
(21,70) .854
(15,20) .598
(14,50)
.571
(13,80)
.543
–RA
= Right Angle
(-P only)
–CA3D
= RG 179 Cable
Die Cast
(–P–ST only)
(29,80) 1.173
(18,70) .736
(17,50)
.689
Hex.
–CA6D
= RG 6 or
Belden
1694A Cable
Die Cast
(–P–ST only)
–BH3
= Bulkhead,
RG 179 Cable
(–J only)
(9,65) .380
–P–ST SHOWN
–J–ST SHOWN
Supplied with pins, ferrules, washers, nuts and gaskets. See website for dimensions.
WWW.SAMTEC.COM
