Phycomp
Product specification
Surface-mount ceramic
multilayer capacitors
FEATURES
•
Five standard sizes
•
High capacitance per unit volume
•
Supplied in tape on reel
•
NiSn terminations.
QUICK REFERENCE DATA
DESCRIPTION
Rated voltage U
R
(DC)
Capacitance range (E6 series)
Tolerance on capacitance
Test voltage (DC) for 1 minute:
Sectional specifications
APPLICATIONS
•
Consumer electronics, for
example:
−
Tuners
−
Television receivers
−
Video recorders
−
All types of cameras
−
Mobile telephones.
terminations
Class 2, Y5V
16/25/50 V
VALUE
16 V, 25 V, 50 V
10 nF to 10
µF;
note 1
±20%
(M);
−20%
to
+80%
(Z)
2.5
×
U
R
IEC 60384-10, second edition 1989-04
based on IEC 60384-10-1
NiSn
30/85/21
Detailed specification
End terminations
Climatic category (IEC 60068)
Note
1. Measured at 25
°C,
1 V and 1 kHz, using a four-gauge method.
DESCRIPTION
The capacitor consists of a
rectangular block of ceramic
dielectric in which a number of
interleaved metal electrodes are
contained. This structure gives rise
to a high capacitance per unit
volume.
The inner electrodes are connected
to the two terminations and finally
covered with a layer of plated tin
(NiSn). A cross section of the
structure is shown in Fig.1.
electrodes
MLB457
ceramic material
Fig.1
Construction of a ceramic multilayer capacitor.
2003 Jul 08 Rev.7
2
www.yageo.com
Phycomp
Product specification
Surface-mount ceramic
multilayer capacitors
MECHANICAL DATA
Class 2, Y5V
16/25/50 V
T
W
L2
L4
L1
L3
MBB211
For dimensions see Table 1.
Fig.2. Component outline.
Physical dimensions
Table 1
Capacitor dimensions; see Fig.2
L
1
W
MIN.
0.5
±0.05
0.8
±0.07
1.25
±0.10
1.6
±0.15
2.5
±0.20
0.020
±0.002
0.032
±0.003
0.049
±0.004
0.063
±0.006
0.098
±0.008
0.45
0.73
0.50
0.50
1.40
0.018
0.029
0.020
0.020
0.047
T
MAX.
0.55
0.87
1.35
1.75
1.60
0.022
0.035
0.053
0.069
0.069
L
2
and L
3
.
MIN.
0.15
0.25
0.25
0.25
0.25
0.008
0.010
0.010
0.010
0.010
MAX.
0.30
0.65
0.75
0.75
0.75
0.012
0.026
0.030
0.030
0.030
L
4
MIN.
CASE SIZE
Dimensions in millimetres
0402
0603
0805
1206
1210
0402
0603
0805
1206
1210
1.0
±0.05
1.6
±0.10
2.0
±0.10
3.2
±0.15
3.2
±0.20
0.040
±0.002
0.063
±0.004
0.079
±0.004
0.126
±0.006
0.126
±0.008
0.40
0.40
0.55
1.40
1.40
0.016
0.016
0.022
0.056
0.056
Dimensions in inches
2003 Jul 08 Rev.7
3
www.yageo.com
Phycomp
Product specification
Surface-mount ceramic
multilayer capacitors
SELECTION CHART FOR 50 V
LAST
TWO
DIGITS
OF
12NC
05
06
07
08
09
11
12
13
14
15
16
17
18
1.25
±0.1
0.85
±0.1
0.8
±0.07
0.6
±0.1
50 V
0603
0805
Class 2, Y5V
16/25/50 V
C
(nF)
1206
10
15
22
33
47
68
100
150
220
330
470
680
1 000
Note
0.6
±0.1
0.85
±0.1
1.15
±0.1
1. Values in shaded cells indicate thickness class in mm.
Thickness classification and packing quantities
THICKNESS
CLASSIFICATION
(mm)
0.5
±0.05
0.6
±0.10
0.8
±0.07
0.85
±0.10
1.15
±0.10
1.25
±0.10
1.5
±0.10
8 mm TAPE WIDTH QUANTITY PER REEL
∅180
mm; 7"
PAPER
10 000
4 000
4 000
4 000
−
−
−
BLISTER
−
−
−
−
3 000
3 000
3 000
∅330
mm; 13"
PAPER
50 000
20 000
15 000
15 000
−
−
−
BLISTER
−
−
−
−
10 000
1 000
−
50 000
−
−
−
−
−
−
−
−
15 000
15 000
−
−
−
−
10 000
−
8 000
−
5 000
−
QUANTITY PER BULK CASE
0402
0603
0805
2003 Jul 08 Rev.7
5
www.yageo.com
