0805 CHIP INDUCTORS
Aerospace Grade Chip Inductors
AE336RAD
The AE336RAA inductors provide exceptional Q values,
even at high frequencies. They have a ceramic body and
wire wound construction to provide the highest SRFs,
tight inductance tolerance and batch consistency.
This robust version of Coilcraft’s standard 0805HQ
series features high temperature materials that pass
NASA low outgassing specifications and allow operation
in ambient temperatures up to 155°C. The leach-resis-
tant base metalization with tin-lead (Sn-Pb) terminations
ensures the best possible board adhesion.
SRF min
5
(GHz)
10.30
6.10
4.75
3.00
2.95
2.55
2.05
2.00
1.95
1.60
1.40
1.40
Part
number
1
Inductance
2
(nH)
2.5
5.6
6.2
12
16
18
20
27
30
39
48
51
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 200 MHz
@ 200 MHz
Percent
tolerance
3
5
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
Q
min
4
DCR max
6
(Ohms)
0.020
0.035
0.035
0.045
0.060
0.060
0.055
0.070
0.095
0.110
0.095
0.120
Imax
(A)
1.6
1.6
1.6
1.6
1.5
1.4
1.4
1.3
1.2
1.1
1.2
1.0
AE336RAD2N5_LZ
AE336RAD5N6_LZ
AE336RAD6N2_LZ
AE336RAD12N_LZ
AE336RAD16N_LZ
AE336RAD18N_LZ
AE336RAD20N_LZ
AE336RAD27N_LZ
AE336RAD30N_LZ
AE336RAD39N_LZ
AE336RAD48N_LZ
AE336RAD51N_LZ
80 @ 1500 MHz
98 @ 1500 MHz
88 @ 1000 MHz
80 @ 1000 MHz
72 @ 500 MHz
75 @ 500 MHz
70 @ 500 MHz
75 @ 500 MHz
65 @ 500 MHz
65 @ 500 MHz
65 @ 500 MHz
65 @ 500 MHz
1. When ordering, please specify
tolerance
and
testing
codes:
AE336RAD51NGLZ
Tolerance: G
= 2%
J
= 5%
Testing:
Z
= Coilcraft Critical Products Environmental Stress
Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening
N
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening
C
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening + MIL-STD-981 Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening + MIL-STD-981 Class S Group B qualification
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/
HP 4286 impedance analyzer with Coilcraft-provided correlation pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture.
5. For SRF less than 6 GHz, measured using an Agilent/HP 8753D network
analyzer and a Coilcraft SMD-D test fixture. For SRF greater than 6 GHz,
measured using an Agilent/HP 8722ES network analyzer and a Coilcraft
SMD-D test fixture.
6. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF840 test fixture.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Core material
Ceramic
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +155 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.23 mm thick, 4 mm pocket spacing,
1.65 mm pocket depth
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document AE197-1
Revised 06/01/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
