SS4-30-3.00-L-D-PA-TR datasheet, PDF

Datasheet> All Categories > The connector> The connector> SS4-30-3.00-L-D-PA-TR

SS4-30-3.00-L-D-PA-TR: DescriptionBoard Stacking Connector; CategoryThe connector The connector; File Size894KB，4 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/

Download Datasheet Parametric View All

SS4-30-3.00-L-D-PA-TR Overview

Board Stacking Connector

SS4-30-3.00-L-D-PA-TR Parametric

Parameter Name	Attribute value
Reach Compliance Code	compliant
ECCN code	EAR99
Connector type	BOARD STACKING CONNECTOR
Manufacturer's serial number	SS4
Base Number Matches	1

Preview

Download Datasheet

View All

REVISION N

DO NOT

SCALE FROM

THIS PRINT

1.76 .069 REF

DESIGNED & DIMENSIONED

IN MILLIMETERS[INCHES]

"A" REF

SS4-XX-X.XX-X-D-X-XX-TR

No OF POSITIONS

-10, -15, -20, -30, -40, -50

(PER ROW)

LEAD STYLE

-3.00: SEE FIG 1

(USE C-229-3.00-X)

-3.50: SEE FIG 2, SHT 2

(USE C-229-3.50-X)

PLATING

-L: 10µ" SELECTIVE GOLD IN CONTACT

AREA, MATTE TIN ON TAIL

(USE C-229-X.XX-X)

ROW SPECIFICATION

-D: DOUBLE

PACKAGING

-TR: TAPE AND REEL

PACKAGING

(SEE NOTE 4)

PLACEMENT PAD

-K: KAPTON PAD

(USE K-500-300)

(SEE FIG 4 & 5, SHT 3)

**-PA: PICK & PLACE WITH

ALIGNMENT PINS

(SEE FIG 6, SHT 4)

(NOT AVAILABLE IN -15 POS)

OPTIONS

*, **-L: LATCHING

(USE WT-40-X.XX-T)

(SEE FIG 3, SHT 2 AND NOTE 3)

(LEAVE BLANK FOR NO OPTION)

"B"

'B'

4.35 .171

REF

1.41 .056

REF

1.00 .039

REF

0.40[.016] (TYP)

(TOL. NON-ACCUMULATIVE)

"C" REF

* = TOOLED ONLY FOR THE -3.00 LEAD STYLE

** = AVAILABLE FOR EXISTING CUSTOMERS ONLY

"A"

SS4-XX-3.00-D

3.50 .138

REF

C-229-3.00-X

0.15 .006

REF (TYP)

2° MAX SWAY

(EITHER DIRECTION)

"E"

1 MAX SWAY (TYP)

(EITHER DIRECTION)

DIE ROLL TO FACE

POSITION 1 END

1.00 .039 REF

0.75 .030 REF

1.150

- 0.025

.0453

- .001

(MEASURED CONTACT

TO CONTACT)

+0.100

+.004

"A"

2.85±0.08 .112±.003

0.10[.004]

5.00 .197

SECTION "A"-"A"

SCALE 5 : 1

DETAIL 'B'

SCALE 15 : 1

SS4-40-3.00-L-D SHOWN

UNLESS OTHERWISE SPECIFIED,

DIMENSIONS ARE IN MILLIMETERS.

TOLERANCES ARE:

DECIMALS

FIG 1

TABLE 2 REF

STACK HEIGHT

ST4 LEAD STYLE

SS4 LEAD STYLE

-1.00

-1.50

-2.50

-3.00

4.0[.16]

4.5[.18]

5.5[.22]

-3.50

PROPRIETARY NOTE

THIS DOCUMENT CONTAINS INFORMATION

CONFIDENTIAL AND PROPRIETARY TO

SAMTEC, INC. AND SHALL NOT BE REPRODUCED

OR TRANSFERRED TO OTHER DOCUMENTS OR

DISCLOSED TO OTHERS OR USED FOR ANY

PURPOSE OTHER THAN THAT WHICH IT WAS

OBTAINED WITHOUT THE EXPRESSED WRITTEN

CONSENT OF SAMTEC, INC.

4.5[.18]

5.0[.20]

6.0[.24]

NOTES:

REPRESENTS A CRITICAL DIMENSION.

2. MINIMUM PUSHOUT FORCE: 2.22N[.5 LB].

3. -L: LATCHING OPTION NOT INTENDED FOR ALIGNMENT TO PCB.

AUTOMATED PLACEMENT IS RECOMMENDED.

4. FOR QUANTITIES UP TO 49 PIECES, NO LEADER, TRAILER, OR REEL WILL BE SUPPLIED.

FOR QUANTITIES OF 50-124 PIECES, NO LEADER OR TRAILER WILL BE SUPPLIED.

F:\DWG\MISC\MKTG\SS4-XX-X.XX-X-D-X-XX-TR-MKT.SLDDRW

.X: 0.3 [.01]

.XX: 0.13 [.005]

.XXX: 0.051 [.0020]

ANGLES

MATERIAL:

DO NOT SCALE DRAWING

SHEET SCALE: 2:1

520 PARK EAST BLVD, NEW ALBANY, IN 47150

PHONE: 812-944-6733

FAX: 812-948-5047

e-Mail: info@SAMTEC.com

code: 55322

DESCRIPTION:

DWG. NO.

INSULATOR: LCP, UL 94 V0, COLOR: BLACK

CONTACT: PHOS BRONZE

LATCH: PHOS BRONZE

0.4mm[.016] SOCKET STRIP ASSEMBLY

SS4-XX-X.XX-X-D-X-XX-TR

4/19/2007

SHEET

BY:

CLAY W
