DATA SHEET
NPN SILICON RF TWIN TRANSISTOR
µ
PA863TD
NPN SILICON RF TRANSISTOR (WITH 2 DIFFERENT ELEMENTS)
IN A 6-PIN LEAD-LESS MINIMOLD
FEATURES
• Low voltage operation
• 2 different built-in transistors (2SC5436, 2SC5800)
Q1: Built-in high gain transistor
f
T
= 12.0 GHz TYP.,
S
21e
2
= 9.0 dB TYP. @ V
CE
= 1 V, I
C
= 10 mA, f = 2 GHz
Q2: Built-in low phase distortion transistor suited for OSC operation
f
T
= 4.5 GHz TYP.,
S
21e
2
= 4.0 dB TYP. @ V
CE
= 1 V, I
C
= 5 mA, f = 2 GHz
• 6-pin lead-less minimold package
BUILT-IN TRANSISTORS
Q1
3-pin thin-type ultra super minimold part No.
2SC5436
Q2
2SC5800
ORDERING INFORMATION
Part Number
Quantity
50 pcs (Non reel)
10 kpcs/reel
Supplying Form
• 8 mm wide embossed taping
• Pin 1 (Q1 Collector), Pin 6 (Q1 Base) face the perforation side of the tape
µ
PA863TD
µ
PA863TD-T3
Remark
To order evaluation samples, consult your NEC sales representative.
Unit sample quantity is 50 pcs.
Because this product uses high-frequency technology, avoid excessive static electricity, etc.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. P15686EJ1V0DS00 (1st edition)
Date Published July 2001 NS CP(K)
Printed in Japan
©
